Hyundai Tucson IV (2020-2024) right turn lamp switch sig Wiring diagrams
This page contains all the electrical diagrams for the component. right turn lamp switch sig, in which he is found in the car Hyundai Tucson IV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right turn lamp switch sig (1 of 3)
BLK WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
ICU JUNCTION BLOCK
ICU-A
ICU-B
ICU-E
ICU-G
IPS 1 CONTROL
IPS 2 CONTROL
IPS 3 CONTROL
IPS CONTROL MODULE
LEFT REAR COMBINATION LAMP (OUT)
LEFT T/SIG FR TELL TAIL
LEFT TURN LAMP SWITCH SIG
LICENSE LAMP
NCA WIRE
PNK/BLK WIRE
REAR VIEW CAMERA
RED/ORG WIRE
RIGHT REAR COMBINATION LAMP (OUT)
RIGHT T/SIG FR TELL TAIL
RIGHT TURN LAMP SWITCH SIG
STOP LAMP
TAIL LAMP
W/ LED
W/ LED W/O LED
W/ REAR VIEW CAMERA
W/O LED
W/O LED W/ LED
W/O REAR VIEW CAMERA
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit, except hybrid nx4 (2 of 4) -> RIGHT TURN LAMP SWITCH SIG
Wiring diagram right turn lamp switch sig (2 of 3)
BLK WIRE
BLU/BLK WIRE
BRN/ORG WIRE
GRN/BLK WIRE
GRY WIRE
ICU JUNCTION BLOCK
ICU-A
ICU-B
ICU-G
IPS 1 CONTROL
IPS 2 CONTROL
IPS 3 CONTROL
IPS CONTROL MODULE
LEFT REAR COMBINATION LAMP (OUT)
LEFT T/SIG FR TELLTAIL
LEFT TURN LAMP SWITCH SIG
NCA WIRE
PNK/BLK WIRE
REAR VIEW CAMERA
RED WIRE
RED/ORG WIRE
RIGHT REAR COMBINATION LAMP (OUT)
RIGHT T/SIG FR TELLTAIL
RIGHT TURN LAMP SWITCH SIG
STOP LAMP
TAIL LAMP
W/ LED
W/ LED W/O LED
W/O LED
W/O LED W/ LED
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit, except hybrid nx4a (2 of 4) -> RIGHT TURN LAMP SWITCH SIG
Wiring diagram right turn lamp switch sig (3 of 3)
BLK WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
ICU JUNCTION BLOCK
ICU-A
ICU-B
ICU-E
ICU-G
IPS 1 CONTROL
IPS 2 CONTROL
IPS 3 CONTROL
IPS CONTROL MODULE
LEFT REAR COMBINATION LAMP (OUT)
LEFT T/SIG FR TELLTAIL
LEFT TURN LAMP SWITCH SIG
LICENSE LAMP
NCA WIRE
PNK/BLK WIRE
REAR VIEW CAMERA
RED/ORG WIRE
RIGHT REAR COMBINATION LAMP (OUT)
RIGHT T/SIG FR TELLTAIL
RIGHT TURN LAMP SWITCH SIG
STOP LAMP
TAIL LAMP
W/ LED
W/ REAR VIEW CAMERA
W/O LED
W/O REAR VIEW CAMERA
WHT WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit, hybrid (2 of 4) -> RIGHT TURN LAMP SWITCH SIG
