Hyundai Tucson IV (2020-2024) e-cvvt fuse Wiring diagrams
This page contains all the electrical diagrams for the component. e-cvvt fuse, in which he is found in the car Hyundai Tucson IV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
e-cvvt fuse wiring diagram (1 of 3)
ALT FUSE
ALTERNATOR
AMS FUSE
AWD ECM
B+1 FUSE
B+2 FUSE
B+3 FUSE
B+4 FUSE
BATTERY
BATTERY JUNCTION BLOCK
BATTERY SENSOR
BLK WIRE
BLOWER FUSE
BLOWER RELAY
BLU WIRE
COOLING FAN CONTROLLER
COOLING FAN FUSE
E-CVVT FUSE
E-CVVT RELAY
E-SHIFTER 1 FUSE
E-SHIFTER 2 FUSE
ELECTRONIC OIL PUMP
ELECTRONIC SHIFT SWITCH
EOP 1 FUSE
EPB 1 FUSE
EPB 2 FUSE
ESC MODULE
FUEL PUMP FUSE
FUEL PUMP RELAY
GRN WIRE
MDPS FUSE
MDPS UNIT
MULTI FUSE 1
PNK WIRE
POWER TAILGATE FUSE
POWER TAILGATE UNIT
PTC HEATER FUSE
PTC HEATER RELAY
REAR HEATED FUSE
REAR HEATED RELAY
RED WIRE
RED/ORG WIRE
SCU
START MOTOR
TO ICU JUNCTION BLOCK (DIAGRAM 3 OF 10)
TO ICU JUNCTION BLOCK (DIAGRAM 5 OF 10)
TO ICU JUNCTION BLOCK (DIAGRAM 6 OF 10)
TO ICU JUNCTION BLOCK (DIAGRAM 7 OF 10)
TRAILER CONNECTOR
TRAILER FUSE
WHT WIRE
YEL WIRE
Go to component -> 2.5l, power distribution circuit, nx4 (1 of 10) -> E-CVVT FUSE
e-cvvt fuse wiring diagram (2 of 3)
ALT FUSE
ALTERNATOR
AMS FUSE
AWD ECM
AWD FUSE
B+1 FUSE
B+2 FUSE
B+3 FUSE
B+4 FUSE
BATTERY
BATTERY JUNCTION BLOCK
BATTERY SENSOR
BLK WIRE
BLOWER FUSE
BLOWER RELAY
BLU WIRE
COOLING FAN CONTROLLER
COOLING FAN FUSE
E-CVVT FUSE
E-CVVT RELAY
E-SHIFTER 1 FUSE
E-SHIFTER 2 FUSE
ECU 2 FUSE
ELECTRONIC OIL PUMP
ELECTRONIC SHIFT SWITCH
EOP 1 FUSE
EPB 1 FUSE
EPB 2 FUSE
ESC MODULE
FUEL PUMP FUSE
FUEL PUMP RELAY
GRN WIRE
MDPS FUSE
MDPS UNIT
MULTI FUSE 1
ORG/ WIRE
PCM
PNK WIRE
POWER TAILGATE FUSE
POWER TAILGATE UNIT
PTC HEATER FUSE
PTC HEATER RELAY
REAR HEATED FUSE
REAR HEATED RELAY
RED WIRE
RED/ORG WIRE
SCU
START MOTOR
TCU 1 FUSE
TO ICU JUNCTION BLOCK (DIAGRAM 3 OF 10)
TO ICU JUNCTION BLOCK (DIAGRAM 5 OF 10)
TO ICU JUNCTION BLOCK (DIAGRAM 6 OF 10)
TO ICU JUNCTION BLOCK (DIAGRAM 7 OF 10)
TO PCB BLOCK (DIAGRAM 2 OF 10)
TRAILER CONNECTOR
TRAILER FUSE
WHT WIRE
Go to component -> 2.5l, power distribution circuit, nx4a (1 of 10) -> E-CVVT FUSE
e-cvvt fuse wiring diagram (3 of 3)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
CAMSHAFT POSITION SENSOR 1 (INTAKE)
CAMSHAFT POSITION SENSOR 2 (EXHAUST)
COMPUTER DATA LINES SYSTEM
CRANKSHAFT POSITION SENSOR
E-CVVT FUSE
E-CVVT RELAY
E/R JUNCTION BLOCK
EGR ACTUATOR
EOP 1 FUSE
EOP 2 FUSE
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ PDM
ICU JUNCTION BLOCK
ICU-B
MAP SENSOR (LEFT REAR OF ENGINE)
MEMORY PWR
MODULE 9 FUSE
MULTI FUSE 1
ON/START I/P
PCB BLOCK
PNK WIRE
PT L-CAN HIGH
PT L-CAN LOW
RED WIRE
TCU 1 FUSE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 2.5l (2 of 8) -> E-CVVT FUSE
