Hyundai Tucson III facelift (2018-2021) control ips 5 wiring diagram
This page shows the only wiring diagram for the component.control ips 5, which is found in the car Hyundai Tucson III facelift (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
control ips 5 wiring diagram (1 of 1)
2.0L
2.4L
ARISU-LT IPS 5
B+2 FUSE
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRAKE FLUID LEVEL SENSOR
BRAKE FLUID SW IN
BRN WIRE
BRN/ORG WIRE
CLOCKSPRING
COMPUTER DATA LINES SYSTEM
CONTROL IPS 5
CRUISE ON/OFF RES+
DRIVER DOOR SW
E/R JUNCTION BLOCK
ENTER
GRN WIRE
GRN/BLK WIRE
GROUP
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
I/P-A
I/P-D
I/P-F
ILL
IPS CONTROL MODULE
LEFT REAR PASS DOOR DOOR SW SW
MULTI FUSE 1
ON/START INPUT
ORG/ WIRE
PARKING BRAKE SW IN
PARKING BRAKE SWITCH
PNK WIRE
PNK/BLK WIRE
PWR GND
RED WIRE
RIGHT REAR DOOR SW
RIGHT STEERING WHEEL REMOTE CONTROL SWITCH
SET-
SMART JUNCTION BLOCK
STEERING WHEEL SWITCH
TRIP
UP DOWN
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (3 of 3) -> CONTROL IPS 5
