Hyundai Tucson III (2015-2018) memory power pnk on/start input Wiring diagram
This page shows the only wiring diagram for the component.memory power pnk on/start input, which is found in the car Hyundai Tucson III (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram memory power pnk on/start input (1 of 1)
2.0L
ABS IND.
AEB IND
AEB SENSOR
B-CAN
BCM (RIGHT END OF DASH)
BLK WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRAKE FLUID LEVEL SENSOR
BRAKE SWITCH FUSE
BRK FLUID LEVEL
BRN/ORG WIRE
C-CAN
C-CAN HIGH
C-CAN LOW
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CONSOLE SWITCH
CRASH PAD SWITCH
DBC SWITCH
ESC IND
ESC OFF
ESC OFF SWITCH
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GROUND
GRY WIRE
GRY/ORG WIRE
HIGH LOW
HOT AT ALL TIMES
HOT IN ON OR START
I/P-A
I/P-C
I/P-E
I/P-F
I/P-G
ILL
INSTRUMENT CLUSTER
IPS CONTROL MODULE
LEAK CURRENT AUTO CUT DEVICE
MEMORY 5 FUSE
MEMORY POWER PNK ON/START INPUT WIRE
MICRO -
MODULE 3 FUSE
MODULE 5 FUSE
MODULE 8 FUSE
ORG/ WIRE
P/BRAKE IND
PARKING BRAKE SWITCH
PARKING BRK SW
PCM (2.0L) ECM (1.6L TURBO)
PNK WIRE
PNK/BLK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/ORG WIRE
REG
SMART JUNCTION BLOCK
SMART KEY CONTROL MODULE
STOP LAMP SWITCH
TRANSCEIVER/
TRANSMISSIONS SYSTEM
Go to component -> Anti-lock brakes circuit (2 of 2) -> MEMORY POWER PNK ON/START INPUT WIRE
