Tire pressure monitoring circuit for Hyundai Tucson II (2009-2015)

BLK WIRE C-CAN TRANSCEIVER CLUSTER FUSE COMPUTER DATA LINES SYSTEM GRN WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT IN ON OR START I/P JUNCTION BOX I/P-F I/P-G INSTRUMENT CLUSTER INTERFACE LEFT FRONT TIRE PRESSURE SENSOR LEFT REAR TIRE PRESSURE SENSOR MEMORY POWER CAN-HIGH GROUND MICOM MODULE 1 FUSE ON/START INPUT CAN-LOW 8 9 10 11 12 ORG/ WIRE RED WIRE RIGHT FRONT TIRE PRESSURE SENSOR RIGHT REAR TIRE PRESSURE SENSOR TIRE PRESSURE MONITORING MODULE (RIGHT SIDE OF DASH) TPMS IND
