Courtesy lamps circuit for Hyundai Tucson II (2009-2015)

B-CAN B-CAN HIGH B-CAN LOW B-CAN TRANSCEIVER BCM (CENTER OF DASH) BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM DIODE (LEFT SIDE OF LUGGAGE COMPT) DOOR ON DOOR OPEN IND DOOR SWITCH DRIVER DOOR SWITCH (LEFT "B" PILLAR) DRIVER VANITY LAMP DRV DR SIG E/R FUSE, RELAY BOX (LEFT FRONT CORNER OF ENGINE COMPT) GRN WIRE GRN/ORG WIRE GRY WIRE GRY/BLK WIRE HIGH LOW HIGH LOW GND HOT AT ALL TIMES I/P JUNCTION BOX I/P-D I/P-H I/P-J INSTRUMENT CLUSTER INTERFACE INTERIOR LAMP RELAY IPS CONTROL MODULE LEFT REAR DOOR SWITCH (LEFT "C" PILLAR) LUGGAGE LAMP MAP LAMP MICOM OFF ON DR ON OFF ORG/ WIRE OVERHEAD CONSOLE PASSENGER DOOR SWITCH (RIGHT "B" PILLAR) PASSENGER VANITY LAMP LH PNK WIRE PNK/BLK WIRE POWER CONNECTOR REAR DRI PASS REAR LH RH RED WIRE RIGHT REAR DOOR SWITCH (RIGHT "C" PILLAR) RLY CTRL ROOM LAMP ROOM LAMP CONTROL ROOM LP FUSE SUNROOF MOTOR TAIL GATE OPEN SW TAIL GATE OPEN SWITCH TAILGATE LATCH TAILGATE OPEN IND W/ SUNROOF WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
