Electronic power steering circuit for Hyundai Tucson II (2009-2015)

1 2 3 4 5 6 7 8 ON/START IN 2 1 BATT PWR GND BLK WIRE C-CAN CAN-HIGH CAN-LOW CLUSTER FUSE EPS CONTROL MODULE (STEERING COLUMN) EPS IND GRN WIRE GRY WIRE GRY/ORG WIRE HOT IN ON OR START I/P JUNCTION BOX I/P-G INSTRUMENT CLUSTER INTERFACE MDPS FUSE MICOM MULTI- ORG/ WIRE RED WIRE TRANSCEIVER/
