Hyundai Tucson II (2009-2015) pnk shift interlock system Wiring diagram
This page shows the only wiring diagram for the component.pnk shift interlock system, which is found in the car Hyundai Tucson II (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk shift interlock system (1 of 1)
26_VFS
4 10 9 8 2 ON/START INPUT SIGNAL 1 SIGNAL 4 SIGNAL 3 SIGNAL 2 PNK WIRE
ATM SHIFT LEVER
ATM SOLENOID VALVE (ON TOP OF TRANSAXLE)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
DOWN SHIFT
E/R-CHGK
EC_VFS
EMS BOX
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
INPUT SPEED SENSOR
LP_VFS
OD_VFS
OIL TEMPERATURE
ORG/ WIRE
OUTPUT SPEED SENSOR
PCM (LEFT REAR OF ENGINE COMPT)
PNK SHIFT INTERLOCK SYSTEM WIRE
PNK WIRE
RED WIRE
SELECT SWITCH
SENSOR
SS A
SS B
SS-B SS-A GND GND DOWN SHIFT UP SHIFT SELECT SWITCH PNK WIRE
STARTING/CHARGING SYSTEM
TCU 1 FUSE (IN E/R FUSE, RELAY BOX)
TRANSAXLE RANGE SWITCH (ON TOP LEFT SIDE OF TRANSAXLE)
UD_VFS
UP SHIFT
WHT WIRE
YEL WIRE
Go to component -> A/t circuit -> PNK SHIFT INTERLOCK SYSTEM WIRE
