Courtesy lamps circuit for Hyundai Tiburon II facelift (2007-2009)

BCM-DE BCM-MR BLK WIRE BODY CONTROL MODULE BOX (BEHIND LEFT SIDE OF DASH) DOOR OFF E/R BOX (IN LEFT FRONT CORNER OF ENGINE COMPT, BEHIND BATTERY) FUSIBLE LINK (BATT) GROUND GROUND BCM-LM HOT AT ALL TIMES OFF ON OFF OVERHEAD CONSOLE LAMP, SUNROOF SWITCH POWER CONNECTOR ROOM LP FUSE RED WIRE ROOM LAMP SOLID STATE TIMER TO BODY CONTROL MODULE BOX (DIAGRAM 2 OF 2) WHT WIRE YEL WIRE

BCM-FF BCM-KM BLK WIRE BODY CONTROL MODULE BOX (BEHIND LEFT SIDE OF DASH) BRN WIRE FROM POWER CONNECTOR (DIAGRAM 1 OF 2) GRN/BLK WIRE GRN/ORG WIRE GRY WIRE GRY/BLK WIRE INSTRUMENT CLUSTER JOINT CONNECTOR LEFT DOOR LAMP LEFT DOOR SW LEFT DOOR SWITCH LUGGAGE ROOM LAMP LUGGAGE ROOM LAMP SWITCH RED WIRE RIGHT DOOR LAMP RIGHT DOOR SW BCM-EF RIGHT DOOR SWITCH TAIL GATE AJAR IND TAILGATE OPEN SWITCH BCM-EF TAILGATE OPEN SWITCH BCM-JM WARNING SYSTEMS YEL WIRE
