Car Wiring Diagrams for Multi-gauge unit circuit for Hyundai Tiburon II (2002-2007)

2.0L 2.0L 2.7L AMP 2 (ON LEFT REAR SIDE OF VEHICLE, AHEAD OF WHEELWELL) BCM-IM BCM-JM BCM-KM BLK WIRE BLU WIRE BLU/BLK WIRE BODY CONTROL MODULE BOX (BEHIND LEFT SIDE OF DASH) BRN WIRE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM CRUISE CONTROL MODULE (ON RIGHT SIDE OF FIREWALL, BEHIND STRUT TOWER) DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) ECM (2.7L) PCM FUSE 16 GRN WIRE GROUND GRY WIRE HOT AT ALL TIMES HOT IN ON OR START ILL INJECTION SIGNAL INPUT INSTAN- TANEOUS FUEL CONSUMP- TION GAUGE INSTRUMENT CLUSTER JOINT CONNECTOR MEMORY POWER MULTI GAUGE UNIT ON/START INPUT ORG/ WIRE PNK/BLK WIRE POWER CONNECTOR 18 RED WIRE SPEED SENSOR TORQUE GAUGE VEHICLE SPEED SENSOR (ON TOP OF TRANSAXLE) VEHICLE SPEED SIGNAL INPUT VOLTAGE GAUGE WHT/BLK WIRE
