Hyundai Tiburon II (2002-2007) interior system lights Wiring diagram
This page shows the only wiring diagram for the component.interior system lights, which is found in the car Hyundai Tiburon II (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram interior system lights (1 of 1)
ACC/ON
ANTENNA
AUDIO
AUDIO REMOCON SWITCH
BCM-KM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BODY CONTROL MODULE BOX (BEHIND LEFT SIDE OF DASH)
BRN WIRE
CLOCK- SPRING
DOWN
FUSE 27
GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
ILL
INTERIOR SYSTEM LIGHTS
JOINT CONNECTOR
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
LEFT TWEETER SPEAKER
LF SPKR
LR SPKR
MEM PWR
MULTIFUNCTION SWITCH (UNDER STEERING COLUMN)
NCA WIRE
ORG/ WIRE
PNK/BLK WIRE
POWER
POWER CONNECTOR
RED WIRE
RF SPKR
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
RIGHT TWEETER SPEAKER
RR SPKR
SEEK
SIGNAL
STEERING WHEEL)
VOLUME-
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, without amplifier -> INTERIOR SYSTEM LIGHTS
