Hyundai Tiburon II (2002-2007) audio remocon switch Wiring diagrams
This page contains all the electrical diagrams for the component. audio remocon switch, in which he is found in the car Hyundai Tiburon II (2002-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram audio remocon switch (1 of 3)
AMP (BEHIND LEFT QUARTER TRIM)
ANTENNA
AUDIO
AUDIO REMOCON SWITCH
BCM-FF
BCM-KM
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BODY CONTROL MODULE BOX (BEHIND LEFT SIDE OF DASH)
BRN WIRE
CLOCK- SPRING
CRUISE CONTROL SYSTEM
DOWN
FUSE 2
FUSE 27
GRN WIRE
GRN/ORG WIRE
GROUND MEM POWER
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
JOINT
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
LEFT TWEETER SPEAKER
MULTIFUNCTION SWITCH (UNDER STEERING COLUMN)
NCA WIRE
ORG/ WIRE
PNK/BLK WIRE
POWER
POWER CONNECTOR 18
RED WIRE
REMOTE FR (+) RR (+) ILL (+) MEMORY PWR
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
RIGHT TWEETER SPEAKER
RL (+) RR (+) FL (+) FR (+) REMOTE GROUND MEM POWER L TWEETER GROUND R TWEETER
RL (-) FL (-) FR (-) RR (-) ILL (-) ACC/ON GROUND RL (+) FL (+)
RL (-) RR (-) FL (-) FR (-)
SEEK
SIGNAL GROUND
STEERING WHEEL)
SUB-WOOFER
VOLUME-
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Radio circuit, with amplifier, with j290 amp -> AUDIO REMOCON SWITCH
Wiring diagram audio remocon switch (2 of 3)
AMP (BEHIND LEFT QUARTER TRIM)
ANTENNA
AUDIO
AUDIO REMOCON SWITCH
BCM-FF
BCM-KM
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BODY CONTROL MODULE BOX (BEHIND LEFT SIDE OF DASH)
BRN WIRE
CLOCK- SPRING
DOWN
FUSE 2
FUSE 27
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
JOINT
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
LEFT TWEETER SPEAKER
MULTIFUNCTION SWITCH (UNDER STEERING COLUMN)
NCA WIRE
ORG/ WIRE
PNK/BLK WIRE
POWER
POWER CONNECTOR 18
RED WIRE
REMOTE FR (+) RR (+) ILL (+) MEMORY PWR
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
RIGHT TWEETER SPEAKER
RL (-) FL (-) FR (-) RR (-) ILL (-) ACC/ON GROUND RL (+) FL (+)
SEEK
SIGNAL GROUND
STEERING WHEEL)
SUB-WOOFER
UNDER TRIM PANEL)
VOLUME-
WHT WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Radio circuit, with amplifier, without j290 amp -> AUDIO REMOCON SWITCH
Wiring diagram audio remocon switch (3 of 3)
ACC/ON
ANTENNA
AUDIO
AUDIO REMOCON SWITCH
BCM-KM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BODY CONTROL MODULE BOX (BEHIND LEFT SIDE OF DASH)
BRN WIRE
CLOCK- SPRING
DOWN
FUSE 27
GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
ILL
INTERIOR SYSTEM LIGHTS
JOINT CONNECTOR
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
LEFT TWEETER SPEAKER
LF SPKR
LR SPKR
MEM PWR
MULTIFUNCTION SWITCH (UNDER STEERING COLUMN)
NCA WIRE
ORG/ WIRE
PNK/BLK WIRE
POWER
POWER CONNECTOR
RED WIRE
RF SPKR
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
RIGHT TWEETER SPEAKER
RR SPKR
SEEK
SIGNAL
STEERING WHEEL)
VOLUME-
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, without amplifier -> AUDIO REMOCON SWITCH
