Hyundai Tiburon I facelift (1999-2002) Supplemental restraint circuit

BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/RED WIRE CONTACT COIL DASH FUSE BOX (BELOW LEFT SIDE OF DASH, AT KICK PANEL) DRIVER AIR BAG DRIVER SEAT BELT PRETENSIONER FUSE 10 FUSE 12 GRN WIRE GRN/WHT WIRE HOT AT ON OR START INITIATOR (LOW SIDE) INITIATOR (HIGH SIDE) SERIAL DATA IN/OUT INSTRUMENT CLUSTER LT GRN WIRE MULTIFUNCTION SWITCH NCA WIRE ORG/ WIRE PASS LOW SIDE PASS HIGH SIDE PASSENGER AIR BAG PASSENGER SEAT BELT PRETENSIONER RED WIRE SRS CONTROL MODULE (AIR BAG) (BELOW REAR OF CENTER CONSOLE) SRS INDICATOR SRS WARNING LAMP GROUND IGNITION LOW HIGH LOW HIGH STEERING WHEEL) WHT WIRE WHT/BLK WIRE
