Back-up lamps circuit for Hyundai Tiburon I facelift (1999-2002)
Back-up lamps circuit
A/T
BACK-UP LIGHT SWITCH (TOP OF TRANSAXLE)
BLK WIRE
DASH FUSE BOX (BELOW LEFT SIDE OF DASH, AT KICK PANEL)
FUSE 9
GRY WIRE
HOT IN ON OR START
LEFT BACK-UP LAMP
LEFT REAR COMBINATION LAMP RIGHT BACK- UP LAMP
M/T
NCA WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED/GRN WIRE
RED/WHT WIRE
RIGHT REAR COMBINATION LAMP
TRANSAXLE RANGE (TR) SWITCH (ON RIGHT SIDE OF TRANSAXLE)
WHT/BLK WIRE
