Instrument cluster circuit for Hyundai Tiburon I (1996-1999)

"ABS" SYSTEM INDICATOR ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE FLUID LEVEL SENSOR (IN BRAKE FLUID RESERVOIR) BRAKE SYSTEM INDICATOR BRN WIRE BRN/GRN WIRE BRN/RED WIRE CHARGE WARNING INDICATOR CRUISE CONTROL MODULE (CENTER OF DASH) CRUISE CONTROL SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM CRUISE INDICATOR DASH FUSE BOX (LEFT KICK PANEL) DATA LINK CONNECTOR (LEFT SIDE OF DASH) DIGITAL CLOCK DIODE DOOR AJAR INDICATOR ELECTRONIC POWER STEERING CONTROL MODULE (LEFT REAR WHEEL WELL) ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF DASH) ENGINE COOLANT TEMPERATURE GAUGE ENGINE COOLANT TEMPERATURE SENDER (RIGHT FRONT OF ENGINE, ON COOLANT OUTLET) EXTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM FASTEN SEAT BELT INDICATOR FUEL GAUGE FUEL SENDER FUEL TANK FUSE 10 FUSE 13 FUSE 6 GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE GRN/YEL WIRE HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HIGH BEAM INDICATOR HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START INSTRUMENT CLUSTER JOINT CONNECTOR (LEFT KICK PANEL) LEFT "C" PILLAR) LEFT TURN INDICATOR LIGHT SWITCH LOW FUEL INDICATOR LT GRN/BLK WIRE LT GRN/YEL WIRE MALFUNCTION INDICATOR LAMP (MIL) (CHECK ENGINE) MULTIFUNCTION SWITCH NCA WIRE O/D OFF INDICATOR OIL PRESSURE INDICATOR OIL PRESSURE SWITCH (LOWER LEFT REAR OF ENGINE) PARKING BRAKE SWITCH POWER DISTRIBUTION SYSTEM RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT TURN INDICATOR SPEEDOMETER SRS "AIR BAG" INDICATOR STARTING/CHARGING SYSTEM TACHOMETER TAILGATE AJAR INDICATOR TRANSAXLE CONTROL MODULE (TCM) (LEFT SIDE OF DASH) TRANSMISSIONS SYSTEM VEHICLE SPEED SENSOR (ON SPEEDOMETER) WARNING SYSTEMS WHT WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
