Hyundai Tiburon I (1996-1999) up/down, left/ right switch down, right wiring diagram
This page shows the only wiring diagram for the component.up/down, left/ right switch down, right, which is found in the car Hyundai Tiburon I (1996-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
up/down, left/ right switch down, right wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DASH FUSE BOX (LEFT SIDE OF DASH)
DOWN LEFT RIGHT
GRN WIRE
HOT IN ACC OR ON
LEFT "C" PILLAR)
LEFT DOOR MOTOR UP/DOWN
LEFT RIGHT
LEFT/RIGHT
MASTER SELECTOR SWITCH
NCA WIRE
POWER DOOR MIRROR SWITCH
PWR DR MIRROR FUSE 13
RED WIRE
RIGHT DOOR MOTOR
UP (+)
UP LEFT
UP/ DOWN LEFT/ RIGHT
UP/DOWN
UP/DOWN, LEFT/ RIGHT SWITCH DOWN, RIGHT
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit -> UP/DOWN, LEFT/ RIGHT SWITCH DOWN, RIGHT
