Hyundai Sonata VIII (2019-2023) passenger front side impact sensor Wiring diagrams
This page contains all the electrical diagrams for the component. passenger front side impact sensor, in which he is found in the car Hyundai Sonata VIII (2019-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
passenger front side impact sensor wiring diagram (1 of 2)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
DRIVER CURTAIN AIR BAG (HIGH)
DRIVER CURTAIN AIR BAG (LOW)
DRIVER FRONT SIDE IMPACT SENSOR
DRIVER FRONT SIDE IMPACT SENSOR HIGH
DRIVER FRONT SIDE IMPACT SENSOR LOW
DRIVER PRESSURE SIDE IMPACT SENSOR
DRIVER PRESSURE SIDE IMPACT SENSOR HIGH
DRIVER PRESSURE SIDE IMPACT SENSOR LOW
DRIVER SEAT BELT BUCKLE SENSOR
DRIVER SEAT BELT RETRACTOR
DRIVER SEAT BELT RETRACTOR HIGH
DRIVER SEAT BELT RETRACTOR LOW
DRIVER SIDE AIR BAG (HIGH)
DRIVER SIDE AIR BAG (LOW)
GRN WIRE
GROUND
GRY WIRE
LH REAR SIDE AIR BAG HIGH
LH REAR SIDE AIR BAG LOW
PASSENGER CURTAIN AIR BAG
PASSENGER CURTAIN AIR BAG HIGH
PASSENGER CURTAIN AIR BAG LOW
PASSENGER FRONT SIDE IMPACT SENSOR
PASSENGER FRONT SIDE IMPACT SENSOR HIGH
PASSENGER FRONT SIDE IMPACT SENSOR LOW
PASSENGER PRESSURE SIDE IMPACT SENSOR
PASSENGER PRESSURE SIDE IMPACT SENSOR HIGH
PASSENGER PRESSURE SIDE IMPACT SENSOR LOW
PASSENGER SEAT BELT BUCKLE SENSOR
PASSENGER SEAT BELT RETRACTOR
PASSENGER SEAT BELT RETRACTOR HIGH
PASSENGER SEAT BELT RETRACTOR LOW
PASSENGER SIDE AIR BAG
PASSENGER SIDE AIR BAG HIGH
PASSENGER SIDE AIR BAG LOW
PNK WIRE
RED WIRE
RH REAR SIDE AIR BAG HIGH
RH REAR SIDE AIR BAG LOW
SRS CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit, except hybrid (3 of 3) -> PASSENGER FRONT SIDE IMPACT SENSOR
passenger front side impact sensor wiring diagram (2 of 2)
