Hyundai Sonata VIII (2019-2023) left blind-spot collision warning unit Wiring diagrams
This page contains all the electrical diagrams for the component. left blind-spot collision warning unit, in which he is found in the car Hyundai Sonata VIII (2019-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
left blind-spot collision warning unit wiring diagram (1 of 7)
BCW IND
BLK WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
DRIVER POWER OUTSIDE MIRROR
DRIVER'S DOOR
EXCEPT HYBRID
GRN WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-C
ICU-G
IPS CONTROL
IPS CONTROL MODULE
L-CAN HIGH
L-CAN LOW
LEFT BLIND-SPOT COLLISION WARNING UNIT
MEMORY POWER OUTPUT
NCA WIRE
ORG/ WIRE
PASSENGER POWER OUTSIDE MIRROR
PNK BCW IND WIRE
PNK WIRE
RED WIRE
RIGHT BLIND-SPOT COLLISION WARNING UNIT
W/ ISG
W/O ISG
WHT WIRE
Go to component -> Blind spot information system circuit -> LEFT BLIND-SPOT COLLISION WARNING UNIT
left blind-spot collision warning unit wiring diagram (2 of 7)
BRN WIRE
C-CAN HI
C-CAN LO
ESC MODULE
GRN WIRE
LANE KEEPING ASSIST UNIT (LINE)
LEFT BLIND-SPOT COLLISION WARNING UNIT
LOCAL-CAN HI
LOCAL-CAN LO
MDPS UNIT
ORG/ WIRE
P-CAN HI
P-CAN LO
PARKING COLLISION AVOIDANCE ASSIST UNIT
REAR VIEW CAMERA
REMOTE CONTROL SMART PARKING ASSIST UNIT
RIGHT BLIND-SPOT COLLISION WARNING UNIT
SMART CRUISE CONTROL UNIT
SURROUND VIEW MONITOR UNIT
W/ BCW/REAR VIEW CAMERA
W/O BCW/REAR VIEW CAMERA
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit, except hybrid (4 of 4) -> LEFT BLIND-SPOT COLLISION WARNING UNIT
left blind-spot collision warning unit wiring diagram (3 of 7)
BRN WIRE
C-CAN HI
C-CAN LO
GRN WIRE
INTEGRATED ELECTRIC BRAKE MODULE
LANE KEEPING ASSIST UNIT (LINE)
LEFT BLIND-SPOT COLLISION WARNING UNIT
MDPS UNIT
ORG/ WIRE
P-CAN HI
P-CAN LO
PARKING COLLISION AVOIDANCE ASSIST UNIT
REAR VIEW CAMERA
REMOTE CONTROL SMART PARKING ASSIST UNIT
RIGHT BLIND-SPOT COLLISION WARNING UNIT
SMART CRUISE CONTROL UNIT
SURROUND VIEW MONITOR UNIT
W/O PCA
WHT WIRE
Go to component -> Computer data lines circuit, hybrid (4 of 4) -> LEFT BLIND-SPOT COLLISION WARNING UNIT
left blind-spot collision warning unit wiring diagram (4 of 7)
A/C CONTROL MODULE
A/C SWITCH
A/V, NAVIGATION HEAD UNIT
AUTOMATIC A/C
BLK WIRE
CLOCKSPRING
CRASH PAD SWITCH (DOWN)
DATA LINK CONNECTOR
DC-DC CONVERTER (AMP)
DC-DC CONVERTER (AUDIO)
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER DOOR NFC MODULE
DRIVER IMS MODULE
DRIVER IMS SWITCH
DRIVER POWER OUTSIDE MIRROR
DRIVER SMART KEY OUTSIDE HANDLE
DRIVER'S DOOR
FET (FIELD EFFECT TRANSISTOR)
FRONT CONSOLE SWITCH
FRONT POWER OUTLET
FRONT USB CHARGER
ICU-E
INSTRUMENT CLUSTER
LEFT BLIND-SPOT COLLISION WARNING UNIT
LEFT FRONT VANITY LAMP
LEFT REAR PERSONAL LAMP
LEFT REAR POWER WINDOW SWITCH
MANUAL A/C
MIC SHIELD
NCA WIRE
ORG/ WIRE
OVERHEAD CONSOLE LAMP
RIGHT BLIND-SPOT COLLISION WARNING UNIT
RIGHT FRONT VANITY LAMP
RIGHT REAR PERSONAL LAMP
ROOM LAMP
STEERING WHEEL STEERING WHEEL HEATED MODULE
SURROUND VIEW MONITOR UNIT
TRUNK LID HANDLE SWITCH, TRUNK LAMP
TRUNK LID LATCH
TWO TURN UNLOCK RELAY
USB JACK
W/ MEMORY
W/ NAVIGATION
W/ NFC
W/ SUNROOF
W/O NAVIGATION W/ NAVIGATION
W/O NFC
W/O SUNROOF
WHT WIRE
Go to component -> Ground distribution circuit, except hybrid (1 of 5) -> LEFT BLIND-SPOT COLLISION WARNING UNIT
left blind-spot collision warning unit wiring diagram (5 of 7)
A/C CONTROL MODULE
A/C SWITCH
A/V, NAVIGATION HEAD UNIT
BLK WIRE
CLOCKSPRING
CRASH PAD SWITCH (DOWN)
DATA LINK CONNECTOR
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER DOOR NFC MODULE
DRIVER IMS MODULE
DRIVER IMS SWITCH
DRIVER POWER OUTSIDE MIRROR
DRIVER SMART KEY OUTSIDE HANDLE
DRIVER'S DOOR
FRONT CONSOLE SWITCH
FRONT POWER OUTLET
FRONT USB CHARGER
HEAD-UP DISPLAY
ICU-E
INSTRUMENT CLUSTER
LEFT BLIND-SPOT COLLISION WARNING UNIT
LEFT FRONT VANITY LAMP
LEFT MIC (SHIELD)
LEFT REAR PERSONAL LAMP
MDPS UNIT
NCA WIRE
ORG/ WIRE
OVERHEAD CONSOLE LAMP
PASSENGER DOOR NFC MODULE
PASSENGER POWER OUTSIDE MIRROR
PASSENGER SMART KEY OUTSIDE HANDLE
PTC HEATER
RIGHT BLIND-SPOT COLLISION WARNING UNIT
RIGHT FRONT VANITY LAMP
RIGHT MIC (SHIELD)
RIGHT REAR PERSONAL LAMP
ROOM LAMP
STEERING WHEEL STEERING WHEEL HEATED MODULE
SURROUND VIEW MONITOR UNIT
SVM
TRUNK LID HANDLE SWITCH, TRUNK LAMP
TWO TURN UNLOCK RELAY
USB JACK
W/ NAVIGATION
W/ NFC
W/ SUNROOF
W/O NAVIGATION
W/O NFC
W/O NFC W/ NFC
W/O SUNROOF
WHT WIRE
Go to component -> Ground distribution circuit, hybrid (1 of 5) -> LEFT BLIND-SPOT COLLISION WARNING UNIT
left blind-spot collision warning unit wiring diagram (6 of 7)
A/C CONTROL MODULE
A/C SWITCH
A/V, NAVIGATION HEAD UNIT
ACC/ON INPUT
ACC/ON OUTPUT
AMP
AMP FUSE
AMP PWR OUTPUT
AUTOMATIC A/C
BLK/ORG WIRE
BLU WIRE
BRN WIRE
CURRENT CUT OFF INPUT
DC-DC CONVERTER (AMP)
DC-DC CONVERTER (AUDIO)
FROM IBU 1 FUSE (DIAGRAM 9 OF 10)
FROM ICU JUNCTION BLOCK (DIAGRAM 5 OF 10)
FROM ICU JUNCTION BLOCK (DIAGRAM 6 OF 10)
FROM ICU JUNCTION BLOCK (DIAGRAM 8 OF 10)
FROM ICU JUNCTION BLOCK (DIAGRAM 9 OF 10)
FROM JOINT CONNECTOR UMA (DIAGRAM 9 OF 10)
FROM MEMORY FUSE (DIAGRAM 6 OF 10)
GRY WIRE
HEAD-UP DISPLAY
IBU
ICU JUNCTION BLOCK
ICU-C
ICU-E
INSTRUMENT CLUSTER
ISG INPUT
LEFT BLIND-SPOT COLLISION WARNING UNIT
MANUAL A/C
MEMORY PWR
MEMORY PWR OUTPUT
MULTI MEDIA FUSE
ON/START INPUT
ORG/ WIRE
PCM
RED WIRE
RIGHT BLIND-SPOT COLLISION WARNING UNIT
SURROUND VIEW MONITOR UNIT
TO AMP (DIAGRAM 9 OF 10)
TO FRONT WIRELESS CHARGER (DIAGRAM 8 OF 10)
W/ AMPLIFIER
W/ ISG
W/ NAVIGATION
W/O AMPLIFIER
W/O ISG
W/O NAVIGATION
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (10 of 10) -> LEFT BLIND-SPOT COLLISION WARNING UNIT
left blind-spot collision warning unit wiring diagram (7 of 7)
ACTIVE AIR FLAP ACTUATOR (LOWER)
AMP
AMP FUSE
B/2
BLE UNIT
BLK WIRE
BLK/PNK WIRE
BLU WIRE
BRN/BLK WIRE
CONTROL
DRIVER DOOR NFC MODULE
DRIVER POWER OUT SIDE MIRROR
FROM MULTI FUSE-1 (DIAGRAM 4 OF 9)
GRN/BLK WIRE
HIGH- MOUNTED STOP LAMP FILTER
IAU
IBU
ICU-A
ICU-B
ICU-C
ICU-E
ICU-F
IPS
IPS CONTROL
IPS CONTROL MODULE
LEFT ACTIVE AIR FLAP ACTUATOR (UPPER)
LEFT BLIND-SPOT COLLISION WARNING UNIT
LEFT HEADLAMP
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP (IN)
LEFT REAR COMBINATION LAMP (OUT)
NCA WIRE
ORG/ WIRE
PASSENGER DOOR NFC MODULE
PNK WIRE
PNK/BLK WIRE
REAR COMBINATION LAMP (CENTER)
RED WIRE
RED/BLK WIRE
RIGHT ACTIVE AIR FLAP ACTUATOR (UPPER)
RIGHT BLIND-SPOT COLLISION WARNING UNIT
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP (IN)
RIGHT REAR COMBINATION LAMP (OUT)
TO FRONT WIRELESS CHARGER (DIAGRAM 6 OF 9)
VESS UNIT
WHT WIRE
Go to component -> Power distribution circuit, hybrid (9 of 9) -> LEFT BLIND-SPOT COLLISION WARNING UNIT
