Hyundai Sonata VIII (2019-2023) driver impact sensor high Wiring diagrams
This page contains all the electrical diagrams for the component. driver impact sensor high, in which he is found in the car Hyundai Sonata VIII (2019-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver impact sensor high (1 of 2)
A/BAG IND FUSE
AIR BAG 1 FUSE
AIR BAG 2 FUSE
B-CAN B-CAN LOW HIGH
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
CLOCKSPRING
CLUSTER FUSE
COMPUTER
COMPUTER DATA LINES SYSTEM
CRASH OUTPUT
CRASH SIGNAL
DATA LINES
DRIVER AIR BAG 1
DRIVER AIR BAG 1 HIGH
DRIVER AIR BAG 1 LOW
DRIVER AIR BAG 2
DRIVER AIR BAG 2 HIGH
DRIVER AIR BAG 2 LOW
DRIVER IMPACT SENSOR HIGH
DRIVER IMPACT SENSOR LOW
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-C
ICU-E
ICU-F
ICU-G
IPS CONTROL MODULE
MEMORY POWER
NCA WIRE
ON/START INPUT
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PAB OFF IND
PASSENGER AIR BAG 1
PASSENGER AIR BAG 1 HIGH
PASSENGER AIR BAG 1 LOW
PASSENGER AIR BAG 2 HIGH
PASSENGER AIR BAG 2 LOW
PASSENGER IMPACT SENSOR HIGH
PASSENGER IMPACT SENSOR LOW
PASSENGER KNEE AIR BAG
PASSENGER KNEE AIR BAG HIGH
PASSENGER KNEE AIR BAG LOW
PASSENGER OCCUPANT DETECTION SENSOR
PNK WIRE
RED WIRE
RELAY ENERGIZED
SRS CONTROL MODULE
STEERING WHEEL)
SYSTEM
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Supplemental restraints circuit, except hybrid (1 of 3) -> DRIVER IMPACT SENSOR HIGH
Wiring diagram driver impact sensor high (2 of 2)
A/BAG IND FUSE
AIR BAG 1 FUSE
AIR BAG 2 FUSE
B-CAN B-CAN LOW HIGH
BLK WIRE
BLU WIRE
BMS CONTROL MODULE
BMS-G
BRN WIRE
C-CAN HIGH
C-CAN LOW
CLOCKSPRING
CLUSTER FUSE
COMPUTER
COMPUTER DATA LINES SYSTEM
CRASH OUTPUT
CRASH SIGNAL
DATA LINES
DRIVER AIR BAG 1
DRIVER AIR BAG 1 HIGH
DRIVER AIR BAG 1 LOW
DRIVER AIR BAG 2
DRIVER AIR BAG 2 HIGH
DRIVER AIR BAG 2 LOW
DRIVER IMPACT SENSOR HIGH
DRIVER IMPACT SENSOR LOW
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-C
ICU-E
ICU-F
ICU-G
IPS CONTROL MODULE
MEMORY POWER
NCA WIRE
ON/START INPUT
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PAB OFF IND
PASSENGER AIR BAG 1
PASSENGER AIR BAG 1 HIGH
PASSENGER AIR BAG 1 LOW
PASSENGER AIR BAG 2
PASSENGER AIR BAG 2 HIGH
PASSENGER AIR BAG 2 LOW
PASSENGER IMPACT SENSOR HIGH
PASSENGER IMPACT SENSOR LOW
PASSENGER KNEE AIR BAG
PASSENGER KNEE AIR BAG HIGH
PASSENGER KNEE AIR BAG LOW
PASSENGER OCCUPANT DETECTION SENSOR
PNK WIRE
RED WIRE
RELAY ENERGIZED
SRS CONTROL MODULE
STEERING WHEEL)
SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit, hybrid (1 of 3) -> DRIVER IMPACT SENSOR HIGH
