Hyundai Sonata VII facelift (2017-2019) rear view camera, trunk lid handle switch Wiring diagrams

This page contains all the electrical diagrams for the component. rear view camera, trunk lid handle switch, in which he is found in the car Hyundai Sonata VII facelift (2017-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rear view camera, trunk lid handle switch (1 of 9)

Wiring diagram rear view camera, trunk lid handle switch for Hyundai Sonata VII facelift (2017-2019) (1 of 9)

Get access

A/V, NAVIGATION HEAD UNIT AUX DET AUX GND AUX L + AUX R + B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE C-CAN HIGH C-CAN LOW CAMERA B+ CAMERA P GND CAMERA V/GND CAMERA V/IN COMPUTER DATA LINES SYSTEM CRASH OUTPUT CRUISE CONTROL SYSTEM ELECTROCHROMIC MIRROR GRN WIRE HOT AT ALL TIMES I/P-E IGPM KEYBOARD GROUND KEYPAD GND KEYPAD SIG LEAK CURRENT AUTO CUT DEVICE MTS KEY MULTI MEDIA FUSE NAVI VOICE (+) NCA WIRE OBC WAKEUP ORG/ WIRE P-CAN HIGH P-CAN LOW PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PWR REAR VIEW CAMERA REAR VIEW CAMERA (PLUG-IN HYBRID) REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH RED WIRE REM CTRL SW GND REM CTRL SW SIG SPDIF OUT (-) SPDIF OUT (-) SPDIF GND SUPPLEMENTAL RESTRAINTS SYSTEM VEH SPD VIDEO GND VIDEO OUT WHT WIRE YEL WIRE

Go to component -> Navigation circuit, hybrid & infinity amplifier (1 of 4) -> REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH

Wiring diagram rear view camera, trunk lid handle switch (2 of 9)

Wiring diagram rear view camera, trunk lid handle switch for Hyundai Sonata VII facelift (2017-2019) (2 of 9)

Get access

A/V, NAVIGATION HEAD UNIT AUX DET AUX GND AUX L + AUX R + B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE C-CAN HIGH C-CAN LOW CAMERA B+ CAMERA P GND CAMERA V/GND CAMERA V/IN COMPUTER DATA LINES SYSTEM CRASH OUTPUT CRUISE CONTROL SYSTEM ELECTROCHROMIC MIRROR GRN WIRE HOT AT ALL TIMES I/P-E IGPM KEYBOARD GROUND KEYPAD GND KEYPAD SIG LEAK CURRENT AUTO CUT DEVICE MTS KEY MULTI MEDIA FUSE NAVI VOICE (+) NCA WIRE OBC WAKEUP ORG/ WIRE P-CAN HIGH P-CAN LOW PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PWR REAR VIEW CAMERA REAR VIEW CAMERA (PLUG-IN HYBRID) REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH RED WIRE REM CTRL SW GND REM CTRL SW SIG SPDIF OUT (-) SPDIF OUT (-) SPDIF GND SUPPLEMENTAL RESTRAINTS SYSTEM VEH SPD VIDEO GND VIDEO OUT WHT WIRE YEL WIRE

Go to component -> Navigation circuit, hybrid mobis & dimension amplifier (1 of 4) -> REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH

Wiring diagram rear view camera, trunk lid handle switch (3 of 9)

Wiring diagram rear view camera, trunk lid handle switch for Hyundai Sonata VII facelift (2017-2019) (3 of 9)

Get access

A/V, NAVIGATION HEAD UNIT AUX DET AUX GND AUX L + AUX R + B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE C-CAN HIGH C-CAN LOW CAMERA B+ CAMERA P GND CAMERA V/GND CAMERA V/IN COMPUTER DATA LINES SYSTEM CRASH OUTPUT CRUISE CONTROL SYSTEM DRIVER DOOR SPEAKER ELECTROCHROMIC MIRROR FL (-) FR (-) GRN WIRE HOT AT ALL TIMES I/P-E IGPM KEYBOARD GROUND KEYPAD GND KEYPAD SIG LEAK CURRENT AUTO CUT DEVICE LEFT FRONT MIDRANGE SPEAKER LEFT REAR DOOR SPEAKER MTS KEY MULTI MEDIA FUSE NCA WIRE OBC WAKEUP ORG/ WIRE P-CAN HIGH P-CAN LOW PASSENGER DOOR SPEAKER PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PWR REAR VIEW CAMERA REAR VIEW CAMERA (PLUG-IN HYBRID) REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH RED WIRE RED/ORG WIRE REM CTRL SW GND REM CTRL SW SIG RIGHT FRONT MIDRANGE SPEAKER RIGHT REAR DOOR SPEAKER RL (+) RR (-) SUPPLEMENTAL RESTRAINTS SYSTEM VEH SPD VIDEO GND VIDEO OUT WHT WIRE

Go to component -> Navigation circuit, hybrid w/o amplifier (1 of 3) -> REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH

Wiring diagram rear view camera, trunk lid handle switch (4 of 9)

Wiring diagram rear view camera, trunk lid handle switch for Hyundai Sonata VII facelift (2017-2019) (4 of 9)

Get access

A/V, NAVIGATION HEAD UNIT AUX DET AUX GND AUX L + AUX R + B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE C-CAN HIGH C-CAN LOW CAMERA B+ CAMERA P GND CAMERA V/GND CAMERA V/IN COMPUTER DATA LINES SYSTEM CRASH OUTPUT CRUISE CONTROL SYSTEM ELECTROCHROMIC MIRROR GRN WIRE HOT AT ALL TIMES I/P-E IGPM KEYBOARD GROUND KEYPAD GND KEYPAD SIG LEAK CURRENT AUTO CUT DEVICE MTS KEY MULTI MEDIA FUSE NAVI VOICE (+) NCA WIRE OBC WAKEUP ORG/ WIRE P-CAN HIGH P-CAN LOW PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PWR REAR VIEW CAMERA REAR VIEW CAMERA (PLUG-IN HYBRID) REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH RED WIRE REM CTRL SW GND REM CTRL SW SIG SPDIF OUT (-) SPDIF OUT (-) SPDIF GND SUPPLEMENTAL RESTRAINTS SYSTEM VEH SPD VIDEO GND VIDEO OUT WHT WIRE YEL WIRE

Go to component -> Radio circuit, hybrid w/ navigation & infinity amplifier (1 of 4) -> REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH

Wiring diagram rear view camera, trunk lid handle switch (5 of 9)

Wiring diagram rear view camera, trunk lid handle switch for Hyundai Sonata VII facelift (2017-2019) (5 of 9)

Get access

A/V, NAVIGATION HEAD UNIT AUX DET AUX GND AUX L + AUX R + B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE C-CAN HIGH C-CAN LOW CAMERA B+ CAMERA P GND CAMERA V/GND CAMERA V/IN COMPUTER DATA LINES SYSTEM CRASH OUTPUT CRUISE CONTROL SYSTEM ELECTROCHROMIC MIRROR GRN WIRE HOT AT ALL TIMES I/P-E IGPM KEYBOARD GROUND KEYPAD GND KEYPAD SIG LEAK CURRENT AUTO CUT DEVICE MTS KEY MULTI MEDIA FUSE NAVI VOICE (+) NCA WIRE OBC WAKEUP ORG/ WIRE P-CAN HIGH P-CAN LOW PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PWR REAR VIEW CAMERA REAR VIEW CAMERA (PLUG-IN HYBRID) REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH RED WIRE REM CTRL SW GND REM CTRL SW SIG SPDIF OUT (-) SPDIF OUT (-) SPDIF GND SUPPLEMENTAL RESTRAINTS SYSTEM VEH SPD VIDEO GND VIDEO OUT WHT WIRE YEL WIRE

Go to component -> Radio circuit, hybrid w/ navigation, mobis & dimension amplifier (1 of 4) -> REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH

Wiring diagram rear view camera, trunk lid handle switch (6 of 9)

Wiring diagram rear view camera, trunk lid handle switch for Hyundai Sonata VII facelift (2017-2019) (6 of 9)

Get access

A/V, NAVIGATION HEAD UNIT AUX DET AUX GND AUX L + AUX R + B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE C-CAN HIGH C-CAN LOW CAMERA B+ CAMERA P GND CAMERA V/GND CAMERA V/IN COMPUTER DATA LINES SYSTEM CRASH OUTPUT CRUISE CONTROL SYSTEM DRIVER DOOR SPEAKER ELECTROCHROMIC MIRROR FL (-) FR (-) GRN WIRE HOT AT ALL TIMES I/P-E IGPM KEYBOARD GROUND KEYPAD GND KEYPAD SIG LEAK CURRENT AUTO CUT DEVICE LEFT FRONT MIDRANGE SPEAKER LEFT REAR DOOR SPEAKER MTS KEY MULTI MEDIA FUSE NCA WIRE OBC WAKEUP ORG/ WIRE P-CAN HIGH P-CAN LOW PASSENGER DOOR SPEAKER PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PWR REAR VIEW CAMERA REAR VIEW CAMERA (PLUG-IN HYBRID) REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH RED WIRE RED/ORG WIRE REM CTRL SW GND REM CTRL SW SIG RIGHT FRONT MIDRANGE SPEAKER RIGHT REAR DOOR SPEAKER RL (+) RR (-) SUPPLEMENTAL RESTRAINTS SYSTEM VEH SPD VIDEO GND VIDEO OUT WHT WIRE

Go to component -> Radio circuit, hybrid w/ navigation w/o amplifier (1 of 3) -> REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH

Wiring diagram rear view camera, trunk lid handle switch (7 of 9)

Wiring diagram rear view camera, trunk lid handle switch for Hyundai Sonata VII facelift (2017-2019) (7 of 9)

Get access

AUDIO AUX DET AUX GND AUX L + AUX R + B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE C-CAN HIGH C-CAN LOW CAMERA B+ CAMERA P GND CAMERA V/GND CAMERA V/IN COMPUTER DATA LINES SYSTEM CRASH OUTPUT CRUISE CONTROL SYSTEM DRIVER DOOR SPEAKER ELECTROCHROMIC MIRROR FL (-) FR (-) GRN WIRE HOT AT ALL TIMES I/P-E IGPM KEYPAD GND KEYPAD SIG LEAK CURRENT AUTO CUT DEVICE LEFT FRONT MIDRANGE SPEAKER LEFT REAR DOOR SPEAKER MTS KEY MULTI MEDIA FUSE NCA WIRE OBC WAKEUP ORG/ WIRE P-CAN HIGH P-CAN LOW PASSENGER DOOR SPEAKER PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PWR REAR VIEW CAMERA REAR VIEW CAMERA (PLUG-IN HYBRID) REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH RED WIRE RED/ORG WIRE REM CTRL SW GND REM CTRL SW SIG RIGHT FRONT MIDRANGE SPEAKER RIGHT REAR DOOR SPEAKER RL (+) RR (-) SUPPLEMENTAL RESTRAINTS SYSTEM VEH SPD VIDEO GND VIDEO OUT WHT WIRE

Go to component -> Radio circuit, hybrid w/o navigation & amplifier (1 of 3) -> REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH

Wiring diagram rear view camera, trunk lid handle switch (8 of 9)

Wiring diagram rear view camera, trunk lid handle switch for Hyundai Sonata VII facelift (2017-2019) (8 of 9)

Get access

AUDIO AUX DET AUX GND AUX L + AUX R + B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE C-CAN HIGH C-CAN LOW CAMERA B+ CAMERA P GND CAMERA V/GND CAMERA V/IN COMPUTER DATA LINES SYSTEM CRASH OUTPUT CRUISE CONTROL SYSTEM ELECTROCHROMIC MIRROR GRN WIRE HOT AT ALL TIMES I/P-E IGPM KEYPAD GND KEYPAD SIG LEAK CURRENT AUTO CUT DEVICE MTS KEY MULTI MEDIA FUSE NAVI VOICE (+) NCA WIRE OBC WAKEUP ORG/ WIRE P-CAN HIGH P-CAN LOW PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PWR REAR VIEW CAMERA REAR VIEW CAMERA (PLUG-IN HYBRID) REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH RED WIRE REM CTRL SW GND REM CTRL SW SIG SPDIF OUT (-) SPDIF OUT (-) SPDIF GND SUPPLEMENTAL RESTRAINTS SYSTEM VEH SPD VIDEO GND VIDEO OUT WHT WIRE YEL WIRE

Go to component -> Radio circuit, hybrid w/o navigation w/ infinity amplifier (1 of 4) -> REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH

Wiring diagram rear view camera, trunk lid handle switch (9 of 9)

Wiring diagram rear view camera, trunk lid handle switch for Hyundai Sonata VII facelift (2017-2019) (9 of 9)

Get access

AUDIO AUX DET AUX GND AUX L + AUX R + B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE C-CAN HIGH C-CAN LOW CAMERA B+ CAMERA P GND CAMERA V/GND CAMERA V/IN COMPUTER DATA LINES SYSTEM CRASH OUTPUT CRUISE CONTROL SYSTEM ELECTROCHROMIC MIRROR GRN WIRE HOT AT ALL TIMES I/P-E IGPM KEYPAD GND KEYPAD SIG LEAK CURRENT AUTO CUT DEVICE MTS KEY MULTI MEDIA FUSE NAVI VOICE (+) NCA WIRE OBC WAKEUP ORG/ WIRE P-CAN HIGH P-CAN LOW PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PWR REAR VIEW CAMERA REAR VIEW CAMERA (PLUG-IN HYBRID) REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH RED WIRE REM CTRL SW GND REM CTRL SW SIG SPDIF OUT (-) SPDIF OUT (-) SPDIF GND SUPPLEMENTAL RESTRAINTS SYSTEM VEH SPD VIDEO GND VIDEO OUT WHT WIRE YEL WIRE

Go to component -> Radio circuit, hybrid w/o navigation w/ mobis & dimension amplifier (1 of 4) -> REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH
