Hyundai Sonata VII facelift (2017-2019) close/ click click Wiring diagram
This page shows the only wiring diagram for the component.close/ click click, which is found in the car Hyundai Sonata VII facelift (2017-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram close/ click click (1 of 1)
BCM
BCM ENABLE
BLK WIRE
BLU WIRE
CLICK
CLICK TILT UP
CLOSE/ CLICK CLICK
CLOSE/ TILT DOWN
CLOSE/ TILT DOWN OPEN
GLASS STATUS SIG
GRN WIRE
GROUND
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
I/P-E
MEMORY PWR
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
OVERHEAD CONSOLE ASSEMBLY
PNK WIRE
POWER WINDOWS SYSTEM
RED WIRE
SAFETY P/WIND ENABLE OUT
SIG A
SIG B
SIG C
SMART JUNCTION BLOCK
SUNROOF 1 FUSE
SUNROOF MOTOR
SUNROOF OPN SW IN
SUNROOF SWITCH
Go to component -> Power top/sunroof circuit, except hybrid w/o panoramic sunroof -> CLOSE/ CLICK CLICK
