Hyundai Sonata VII (2014-2017) Navigation circuit, hybrid w/o mobis & jbl amplifier

A/V TAIL A/V, NAVIGATION HEAD UNIT AUDIO AUX DETECT AUX L IN AUX R IN AUX VIDEO GROUND AUX VIDEO IN AUX-GROUND BCM BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE CALL OFF CALL ON CAMERA B+ CAMERA V/IN CLOCK- SPRING COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM FL (-) FR (-) GRN WIRE GROUND HOT AT ALL TIMES HOT W/ ACC RELAY ENERGIZED I/P-E I/P-F ILL ILL (+) BACK-UP SIGNAL ILL(-) ANTENNA LEAK CURRENT AUTO CUT DEVICE LEFT AUDIO/BLUETOOTH REMOTE CONTROL SWITCH M-CAN HIGH M-CAN LOW MEMORY POWER MIC (+) ACC/ON INPUT MIC GROUND MODE SEEK DOWN MODULE 2 FUSE MODULE 6 FUSE MULTI MEDIA FUSE NCA WIRE ON/START INPUT ORG/ WIRE PNK WIRE RED WIRE RELAY ENERGIZED RL (+) RR (+) CAMERA P GROUND RR (-) CAMERA V/GROUND SEEK UP SIGNAL SMART JUNCTION BLOCK STEERING WHEEL) TAIL AV USB D (-) USB VCC USB D- USB GROUND VEHICLE SPEED VOICE VOL (-) WHT WIRE YEL WIRE

BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE CAMERA DRIVER DOOR SPEAKER GRN WIRE GROUND LEFT FRONT TWEETER SPEAKER LEFT REAR DOOR SPEAKER MIC (MICROPHONE) MIC - NCA WIRE ORG/ WIRE OUT PASSENGER DOOR SPEAKER POWER REAR VIEW CAMERA REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH RED WIRE RIGHT FRONT TWEETER SPEAKER RIGHT REAR DOOR SPEAKER VIDEO+ WHT WIRE YEL WIRE

A/V, NAVIGATION HEAD UNIT ANT-CG ANT-CSC AUX DETECT AUX L + AUX R + AUX VIDEO OUT - AUX, USB JACK AUX-GROUND BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/RED WIRE BPF BRN WIRE CDMA CDMA OUT CIRCUIT COMBI ANTENNA GLASS ANTENNA GPS GPS OUT/B+ GRN WIRE GROUND ILL KEYBOARD GROUND LNA MATCHING CIRCUIT NCA WIRE RED WIRE RFC SDARS SDARS OUT USB D- USB GROUND USB VCC WHT WIRE WHT/BLK WIRE WHT/BLU WIRE
