Forced entry circuit, hybrid w/o ims for Hyundai Sonata VII (2014-2017)

2.0L PLUG-IN HYBRID AJAR AUTO LIGHT SIG AUTO LIGHT, PHOTO SENSOR B-CAN B-CAN HIGH B-CAN LOW BCM (LOWER CENTER OF DASH) BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DOOR DOOR LK DRIVER DOOR DRIVER DOOR LOCK ACTUATOR GRN WIRE GRY WIRE HDLP SW (HI) HEADLIGHTS SYSTEM HIGH SW HOT AT ALL TIMES HOT W/ I/P-F I/P-G I/P-H ICM RELAY BOX (UPPER LEFT CENTER OF DASH) INTEGRATED BRAKE ACTUATION UNIT IPS CONTROL MODULE KEY KEY LK UNLK SIG SIG LEAK CURRENT AUTO CUT DEVICE LK/ UNLK SIG LT DR LP OUT MEMORY 1 FUSE MODULE 8 FUSE ON INPUT ORG/ WIRE PNK WIRE RED WIRE RT DR LP OUT SECURITY IND SMART JUNCTION BLOCK TWO TURN UNLOCK RELAY UNLK W/ TWO TURN UNLOCK W/O TWO TURN UNLOCK WHT WIRE YEL WIRE

2.0L PLUG-IN HYBRID AJAR BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CHARGE PORT DOOR LOCK/ UNLOCK ACTUATOR DOOR LK DOOR LK DOOR UNLK DOOR LOCK RELAY DOOR LOCK SWITCH DOOR SW DOOR UNLK DOOR UNLOCK RELAY DR LOCK FUSE GRY WIRE HOT AT ALL TIMES I/P-D I/P-E I/P-F I/P-H IPS CONTROL MODULE LEFT REAR DOOR LOCK ACTUATOR LK/UNLK SIG LOCK LR DOOR LK/ LR DOOR SW ORG/ WIRE ORG/BLK WIRE PASS PASS DOOR PASSENGER POWER WINDOW MAIN SWITCH PNK WIRE RED WIRE RIGHT REAR DOOR LOCK ACTUATOR RLY CTRL RR DOOR LK/ RR DOOR SW SMART JUNCTION BLOCK TURN UNLK TWO UNLK SIG UNLOCK W/ TWO TURN UNLOCK W/O TWO TURN UNLOCK WHT WIRE YEL WIRE

AJAR BLK WIRE BLU WIRE BRN WIRE BURGLAR ALARM BURGLAR ALARM HORN BURGLAR ALARM HORN RELAY DOOR LK DOOR LK SW LK DOOR LK SW UNLK DOOR LOCK SWITCH DOOR UNLK E/R JUNCTION BLOCK E/R-E GRN WIRE H/LP LOW SIG HAZARD SIG HEADLIGHTS SYSTEM HOOD SW HOOD SWITCH HORN FUSE HORN RLY CTRL HOT AT ALL TIMES I/P-B I/P-C I/P-F I/P-H ICM RELAY BOX IPS CONTROL MODULE LOCK NCA WIRE ORG/ WIRE PASSENGER DOOR LOCK ACTUATOR PCB BLOCK PNK WIRE PNK/BLK WIRE POWER WINDOW MAIN SWITCH RED WIRE SMART JUNCTION BLOCK UNLOCK WHT WIRE YEL WIRE
