Hyundai Sonata VII (2014-2017) -set cancel Wiring diagrams
This page contains all the electrical diagrams for the component. -set cancel, in which he is found in the car Hyundai Sonata VII (2014-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram -set cancel (1 of 3)
-SET CANCEL
APS 1 GROUND
APS 1 POWER
APS 1 SIGNAL
APS 2 GROUND
APS 2 POWER
APS 2 SIGNAL
BLK WIRE
BLU WIRE
BRAKE LIGHT SW
BRAKE SIG
BRAKE TEST SW
BRN WIRE
C-CAN HIGH
C-CAN LOW
CLOCK- SPRING
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CRUISE ON/OFF
DOWN
E/R JUNCTION BLOCK
E/R-D
ECU 2 FUSE
ENTER
ETC OUTPUT (+)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HPCU
HYBRID POWER CONTROL UNIT (TOP OF TRANSAXLE)
I/P-E
I/P-G
ILL
LEAK CURRENT AUTO CUT DEVICE
MEM POWER
MEMORY 1 FUSE
NCA WIRE
ORG/ WIRE
PCB BLOCK
PCM
PNK WIRE
RED WIRE
RELAY ENERGIZED
RES+
RIGHT TRIP/CRUISE REMOTE CONTROL SWITCH
SCC
SMART JUNCTION BLOCK
STEERING WHEEL)
STOP LP SW
TPS 1 SIGNAL
TPS 2 SIGNAL
TPS GROUND
TPS SUPPLY
TRIP
UP GROUP
VEHICLE SPD IN
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit, hybrid (1 of 3) -> -SET CANCEL
Wiring diagram -set cancel (2 of 3)
-SET CANCEL
AMP
AUTO HOLD (WHITE/YELLOW/ GREEN) IND
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRAKE IND
CLOCK
CLOCK SPRING (REMOTE CONTROL)
COMPUTER DATA LINES SYSTEM
CONSTANT
CRUISE IND
CRUISE ON/OFF
CURRENT
DAC
DECENT OUT (+)
DETENT
DIAL ILL
DIGITAL CLOCK
DOWN
ECO IND
ENTER
FLASH MEMORY
FROM TFT LCD (DIAGRAM 1 OF 3)
FROM TPMS IND (DIAGRAM 1 OF 3)
FRONT FOG IND
GRN WIRE
GROUND
GRY WIRE
GRY/BLK WIRE
HAZARD SWITCH
ILL
ILL (-) OUT
IMMO IN 3
IMMO IND
INSTRUMENT CLUSTER
LAMP IN
LCD DRIVER
LEFT TURN IND
LOW BEAM IND
M-CAN HIGH
M-CAN LOW
MEMORY POWER
MICOM
ON/START INPUT
ORG/ WIRE
ORG/BLK WIRE
PAB OFF
PASS SEAT BELT IND
PNK ACC/ON INPUT WIRE
PNK WIRE
PNK/BLK WIRE
POINTER ILL
PPL
RED WIRE
RED/BLK WIRE
RES+
RHEOSTAT DOWN IN 4
RHEOSTAT UP IN
RIGHT TRIP/CRUISE REMOTE CONTROL SWITCH
RIGHT TURN IND
SCC
SEG LCD FUEL
SEG LCD ILL
SEG LCD TEMP
SET IND
SPEAKER OUT -
SPEED OUT
SPEEDO- METER
SPORT IND
STEERING WHEEL)
SUPERVISION
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHO- METER
TAIL
TAIL ON IND
TEMPERATURE METER
TRIP
UP GROUP
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit, except hybrid (3 of 3) -> -SET CANCEL
Wiring diagram -set cancel (3 of 3)
-SET CANCEL
2.0L HYBRID
2.0L PLUG-IN HYBRID
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRAKE IND
BRN WIRE
CLOCK
CLOCK- SPRING
COMPUTER DATA LINES SYSTEM
CONSTANT CURRENT
CRUISE IND
CRUISE ON/OFF
DETENT
DETENT OUT
DIAL LCD ILL
DIGITAL CLOCK
DIMMING CIRCUIT
DOWN
ECO IND
ECO/POWER METER
ENTER
ESC IND
EV MOD IND
EXTERNAL MEMORY
FROM TFT LCD (DIAGRAM 1 OF 3)
FROM TPMS IND (DIAGRAM 1 OF 3)
FRONT FOG IND (2.0L HYBRID)
FUEL GAUGE
GROUND
GRY WIRE
HAZARD SWITCH
HIGH BEAM IND
IIL (-) OUT
ILL
IMMO IN 3
INSTRUMENT CLUSTER
INTERFACE
LAMP IN
LEFT TURN IND
M-CAN HIGH
M-CAN LOW
MEMORY POWER
MICOM
NCA WIRE
ORG/ WIRE
PAB OFF (2.0L PLUG-IN HYBRID)
PNK ACC/ON INPUT WIRE
PNK ON/START INPUT WIRE
PNK WIRE
POINTER ILL
READY IND
REAR FOG IND (2.0L HYBRID)
RED WIRE
RES+
RHEOSTAT DOWN IN
RHEOSTAT UP IN
RIGHT TRIP/CRUISE REMOTE CONTROL SWITCH
RIGHT TURN IND
SBR
SCC
SET IND
SOC GAUGE
SOUND GENERATOR
SPEAKER OUT -
SPEED OUT
SPEEDOMETER
STEERING WHEEL)
SUPPLEMENTAL RESTRAINTS SYSTEM
TAIL
TAIL ON IND
TEMPERATURE GAUGE
TRIP
UP GROUP
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit, hybrid (3 of 3) -> -SET CANCEL
