Hyundai Sonata VII (2014-2017) on/str input Wiring diagram
This page shows the only wiring diagram for the component.on/str input, which is found in the car Hyundai Sonata VII (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram on/str input (1 of 1)
2.0L TURBO
2.4L
ANTENNA COIL
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE SWITCH FUSE
BRN WIRE
C-CAN TRANSCEIVER
COIL
COMPUTER DATA LINES SYSTEM
EMS
GRN WIRE
GROUND
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-E
I/P-G
IGNITION KEY
IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH
IMMO DATA LINE
IMMO IND
IMMOBILIZER MODULE (LEFT CENTER OF DASH)
IND
INPUT SIG INTERFACE
INSTRUMENT CLUSTER
K LINE
K-LINE SIG INTERFACE
LEAK CURRENT AUTO CUT DEVICE
MEM PWR
MEMORY 1 FUSE
MICOM
MICRO CONTROLLER
MODULE 4 FUSE
NCA WIRE
ON/STR INPUT
ORG/ WIRE
PCM (2.4L, 2.0L TURBO) ECM (1.6L TURBO)
PNK WIRE
PWR SUPPLY REGULATION
SERIAL SIG INTERFACE
SMART JUNCTION BLOCK
TRANSPONDER
TRANSPONDER READER IC
WHT WIRE
Go to component -> Immobilizer circuit, except hybrid w/o smart key system -> ON/STR INPUT
