Hyundai Sonata VII (2014-2017) flex ray lo Wiring diagrams
This page contains all the electrical diagrams for the component. flex ray lo, in which he is found in the car Hyundai Sonata VII (2014-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram flex ray lo (1 of 2)
1.6L TURBO EXCEPT 1.6L TURBO
2.0L TURBO
2.4L
ABS 2 FUSE
B-CAN HI
B-CAN LO
BLK WIRE
BRN WIRE
C-CAN HI
C-CAN LO
CCP CAN HI
CCP CAN LO
E/R JUNCTION BLOCK
ECM (1.6L TURBO)
ESC MODULE
EXCEPT 2.4L
FLEX RAY HI
FLEX RAY LO
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-C
I/P-F
IPS CONTROL MODULE
LOCAL-CAN HI
LOCAL-CAN LO
MODULE 6 FUSE
MULTI FUSE (TYPE B)
MULTIPURPOSE CHECK CONNECTOR
ORG/ WIRE
PCM
PNK WIRE
SMART CRUISE CONTROL UNIT
SMART JUNCTION BLOCK
SPORT MODE SWITCH
TCM (1.6L TURBO) (TOP OF TRANSAXLE)
VACUUM PUMP
W/ ACC
W/ EPB
W/O ACC
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit, except hybrid (4 of 4) -> FLEX RAY LO
Wiring diagram flex ray lo (2 of 2)
