Hyundai Sonata VII (2014-2017) bsd switch Wiring diagrams
This page contains all the electrical diagrams for the component. bsd switch, in which he is found in the car Hyundai Sonata VII (2014-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram bsd switch (1 of 2)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BSD IND
BSD INDICATOR
BSD ON/OFF SWITCH
BSD SWITCH
C-CAN HIGH
C-CAN LOW
C-CAN PR LOW
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH
DRIVER POWER OUTSIDE MIRROR
GRN WIRE
GROUND
GRY WIRE
HOT IN ON OR START
I/P-F
ILL
LEFT "C" PILLAR)
LEFT BLIND SPOT DETECTION RADAR
MODULE 5 FUSE
NCA WIRE
ON/START INPUT
PASSENGER POWER OUTSIDE MIRROR
PNK C-CAN (PR) HIGH WIRE
PNK/BLK WIRE
RED WIRE
RED/ORG WIRE
RIGHT BLIND SPOT DETECTION RADAR
SMART JUNCTION BLOCK
STATUS LED (ON/OFF SWITCH)
WHT WIRE
WHT/BLK WIRE
Go to component -> Blind spot information system circuit, except hybrid -> BSD SWITCH
Wiring diagram bsd switch (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
BSD IND
BSD INDICATOR
BSD ON/OFF SWITCH
BSD SWITCH
C-CAN HIGH
C-CAN LOW
C-CAN PR HIGH
C-CAN PR LOW
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH
DRIVER POWER OUTSIDE MIRROR
GRN WIRE
GROUND
I/P-D
ILL
LEFT "C" PILLAR)
LEFT BLIND SPOT DETECTION RADAR
MODULE 7 FUSE
NCA WIRE
ON/START INPUT
ORG/ WIRE
PASSENGER POWER OUTSIDE MIRROR
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RELAY ENERGIZED
RIGHT BLIND SPOT DETECTION RADAR
SMART JUNCTION BLOCK
STATUS LED (ON/OFF SWITCH)
WHT WIRE
Go to component -> Blind spot information system circuit, hybrid -> BSD SWITCH
