Hyundai Sonata VI (2009-2014) Wiring diagram engine performance 2.4l hybrid, virtual engine sound system circuit

ACC/ON INPUT BLK WIRE BLU WIRE BRN WIRE CLOCK FUSE COMPUTER DATA LINES SYSTEM HIGH LOW (RIGHT SIDE OF C-CAN HVAC UNIT) (-) HOT AT ALL TIMES HOT IN ACC OR ON I/P JUNCTION BOX I/P-E I/P-G MEMORY POWER MODULE 3 FUSE NCA WIRE ORG/ WIRE POWER DISTRIBUTION SYSTEM RED WIRE VESS SPEAKER (LEFT FRONT WHEELWELL) VESS UNIT WHT WIRE
