Hyundai Sonata VI (2009-2014) two turn unlock relay wiring diagram
This page shows the only wiring diagram for the component.two turn unlock relay, which is found in the car Hyundai Sonata VI (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
two turn unlock relay wiring diagram (1 of 1)
A/C A/C CONTROL CONTROL MODULE MODULE
AUDIO LIGHT, PHOTO SENSOR
BCM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
CLOCK ELECTRO IGNITION CHROMIC KEY ILL, MIRROR DOOR WARNING SWITCH
CONTROL
DATA LINK CONNECTOR
DOOR DOOR UNLOCK LOCK RELAY RELAY
DR LOCK FUSE
DRIVER DOOR LAMP
DRIVER POWER OUTSIDE MIRROR
FROM B+2 FUSE (DIAGRAM 1 OF 6)
FROM DR LOCK FUSE (DIAGRAM 3 OF 6)
GRN/BLK WIRE
I/P JUNCTION BOX
I/P-A
I/P-B
I/P-C
I/P-E
I/P-G
INSTRUMENT CLUSTER
IPS 1
IPS 1 IPS 4 IPS 9
IPS 4
IPS 6
IPS 7
IPS 7 IPS 6
IPS 9 (TWIN)
IPS CONTROL MODULE
LEFT HEAD- LAMP
LEFT REAR COMBINATION LAMP (IN)
LEFT REAR COMBINATION LAMP (OUT)
LEFT REAR PASSENGER COMBINATION POWER LAMP (OUT) OUTSIDE MIRROR
LICENSE LAMP (TRUNK LID SWITCH, REAR CAMERA)
MANUAL AUTO A/C A/C
NCA WIRE
ORG/ WIRE
PASSENGER DOOR LAMP
PNK WIRE
POWER CONNECTOR ROOM LP FUSE
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RF RECEIVER
RIGHT HEAD- LAMP
RIGHT REAR COMBINATION LAMP (IN)
RIGHT REAR COMBINATION LAMP (OUT)
RIGHT REAR INSTRUMENT COMBINATION CLUSTER LAMP (OUT)
ROOM LAMP GLOVE RELAY BOX LAMP
SUNROOF FUSE
SUNROOF PANORAMA MOTOR SUNROOF MOTOR
T/SIG SOUND RELAY
T/SIG SOUND RLY CTRL
TIRE PRESSURE MONITORING MODULE
TO ROOM LP FUSE (DIAGRAM 3 OF 6)
TRUNK ROOM LAMP
TWO TURN UNLOCK RELAY
W/ NAVI
W/ PANO- RAMA
W/ W/O SMART SMART KEY KEY
W/O NAVI
W/O PANO- RAMA
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (3 of 6) -> TWO TURN UNLOCK RELAY
