Hyundai Sonata VI (2009-2014) trunk op switch Wiring diagram
This page shows the only wiring diagram for the component.trunk op switch, which is found in the car Hyundai Sonata VI (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk op switch (1 of 1)
B-CAN
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
FUEL FILLER ACTUATOR (LEFT SIDE OF TRUNK)
FUEL FILLER DOOR SWITCH PNK WIRE
FUEL FILLER DOOR, TRUNK LID SWITCH
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
I/P JUNCTION BOX (LEFT SIDE OF DASH)
I/P-A
I/P-A I/P-D
I/P-D
I/P-F
IPS CONTROL MODULE
LEFT "C" PILLAR)
LOW HIGH
ORG/ WIRE
PNK WIRE
POWER ROOM CONNECTOR LP FUSE
RED WIRE
TRUNK FUSE
TRUNK LID RELAY
TRUNK LID RLY CTRL
TRUNK LID SWITCH
TRUNK OP SWITCH
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH MOTOR PTC
WHT WIRE
YEL WIRE
Go to component -> Trunk & fuel door release circuit, except hybrid -> TRUNK OP SWITCH
