Hyundai Sonata VI (2009-2014) rly ctrl 77 60 chtg-bg c-can hi c-can lo Wiring diagram
This page shows the only wiring diagram for the component.rly ctrl 77 60 chtg-bg c-can hi c-can lo, which is found in the car Hyundai Sonata VI (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rly ctrl 77 60 chtg-bg c-can hi c-can lo (1 of 1)
18 33 53 RLY CTRL HI RLY CTRL LO ECU
BLK WIRE
BLU WIRE
BLU/ORG WIRE
C/FAN FUSE
C/FAN HI FUSE
C/FAN RELAY
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR (BEHIND RADIATOR)
E/R FUSE, RELAY BOX
E/R-A
E/R-B
ECT GND CHTG-AG
ECT SIG
ECU 1 FUSE
ECU RELAY
EMS BOX
ENGINE COOLANT TEMPERATURE SENSOR (REAR OF CYLINDER HEAD)
HOT AT ALL TIMES
MULTI FUSE
NCA WIRE
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
RED WIRE
RLY CTRL 77 60 CHTG-BG C-CAN HI C-CAN LO
SENSOR 1 FUSE
WHT WIRE
YEL WIRE
Go to component -> 2.0l, cooling fan circuit -> RLY CTRL 77 60 CHTG-BG C-CAN HI C-CAN LO
