Hyundai Sonata VI (2009-2014) low voltage active e/r fuse, dc-dc air flap relay box converter Wiring diagram
This page shows the only wiring diagram for the component.low voltage active e/r fuse, dc-dc air flap relay box converter, which is found in the car Hyundai Sonata VI (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low voltage active e/r fuse, dc-dc air flap relay box converter (1 of 1)
A/C CONTROL MODULE
BCM
BLK WIRE
BLK/ORG WIRE
CLOCK
DATA LINK CONNECTOR
DOOR LOCK RELAY
DOOR UNLOCK RELAY
ELECTRIC ELECTRIC OIL PUMP OIL PUMP SHIELD SHIELD
ELECTRIC OIL PUMP UNIT
ELECTRIC WATER PUMP
ELECTRO- CHROMIC MIRROR
EPS ESC CONTROL MODULE MODULE
FUEL FILLER DOOR, TRUNK LID SWITCH
GND (DRL)
GND (ECU)
HYBRID COMPRESSOR
HYBRID CONTROL UNIT
HYDRAULIC POWER UNIT
I/P-E
I/P-F
I/P-G
INSTRUMENT CLUSTER
IPS CONTROL MODULE
JOINT
LEFT VANITY LAMP
LOW VOLTAGE ACTIVE E/R FUSE, DC-DC AIR FLAP RELAY BOX CONVERTER
MULTIFUNCTION SWITCH
PANORAMA SUNROOF PANORAMA SWITCH SUNROOF
PDM
REAR CAMERA MODULE
RHEOSTAT
RIGHT OVERHEAD VANITY CONSOLE LAMP LAMP
ROOM LAMP
SMART KEY MODULE
T/TURN DOOR UNLOCK RELAY
TIRE PRESSURE MONITORING MODULE
VESS UNIT
Go to component -> Ground distribution circuit, hybrid (2 of 4) -> LOW VOLTAGE ACTIVE E/R FUSE, DC-DC AIR FLAP RELAY BOX CONVERTER
