Hyundai Sonata VI (2009-2014) aux, usb clock jack Wiring diagram
This page shows the only wiring diagram for the component.aux, usb clock jack, which is found in the car Hyundai Sonata VI (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram aux, usb clock jack (1 of 1)
A/V, A/C CONTROL NAVIGATION HEAD UNIT MODULE
AMP FUSE
AUDIO
AUX, USB CLOCK JACK
BLU WIRE
BMS CONTROL MODULE
BMS FUSE
CONTROL
DRIVER MANUAL SWITCH
ESC OFF SWITCH
FROM AMP FUSE (DIAGRAM 4 OF 6)
FROM B+4 FUSE (DIAGRAM 1 OF 6)
FRONT
HAZARD FRONT SWITCH MONITOR
I/P-A
I/P-B
I/P-C
I/P-G
IPS 2
IPS 3
IPS 5
IPS 5 IPS 2 IPS 3
IPS 8
IPS CONTROL IPS 8 CONTROL MODULE
IPS CONTROL MODULE
JBL AMP
LEFT FRONT FOG LAMP
LEFT REAR POWER WINDOW SWITCH
LEFT REAR SEAT WARMER SWITCH
MULTI- FUNCTION SWITCH
NAVI
ORG/ WIRE
P/SEAT DRI FUSE
PNK WIRE
POWER WINDOW MAIN SWITCH
RED WIRE
RHEOSTAT
RIGHT FRONT FOG LAMP
RIGHT HEAD- LAMP
RIGHT REAR PASSENGER POWER POWER WINDOW WINDOW SWITCH SWITCH
RIGHT REAR SEAT WARMER SWITCH
SEAT WARMER SWITCH
SPORT MODE SWITCH IND
TO IPS 8 (DIAGRAM 4 OF 6)
TO START 2 FUSE (DIAGRAM 6 OF 6)
W/ NAVI
W/O NAVI
W/O W/ FRONT FRONT MONITOR MONITOR
WHT WIRE
Go to component -> Power distribution circuit, hybrid (4 of 6) -> AUX, USB CLOCK JACK
