Hyundai Sonata VI (2009-2014) auto light, photo sensor front clock rf monitor receiver Wiring diagram
This page shows the only wiring diagram for the component.auto light, photo sensor front clock rf monitor receiver, which is found in the car Hyundai Sonata VI (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto light, photo sensor front clock rf monitor receiver (1 of 1)
A/C CONTROL MODULE
AUTO LIGHT, PHOTO SENSOR FRONT CLOCK RF MONITOR RECEIVER
BCM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CONTROL
DATA LINK CONNECTOR
DIODE
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DR LOCK FUSE
DRIVER DOOR LAMP
DRIVER POWER OUTSIDE MIRROR
E/R FUSE, RELAY BOX
ELECTRO- CHROMIC MIRROR
FROM B+2 FUSE (DIAGRAM 1 OF 6)
FROM DR LOCK FUSE (DIAGRAM 3 OF 6)
GLOVE INSTRUMENT BOX CLUSTER LAMP
GRN WIRE
GRN/BLK WIRE
GRY WIRE
I/P JUNCTION BOX
I/P-A
I/P-B
I/P-C
I/P-E
I/P-G
IPS 1
IPS 1 IPS 4 IPS 9
IPS 4
IPS 6
IPS 7
IPS 7 IPS 6
IPS 9 (TWIN)
IPS CONTROL MODULE
LEFT HEAD- LAMP
LEFT REAR COMBINATION LAMP (IN)
LEFT REAR COMBINATION LAMP (OUT)
LEFT REAR PASSENGER COMBINATION POWER LAMP (OUT) OUTSIDE MIRROR
LICENSE LAMP (TRUNK LID SWITCH, REAR CAMERA)
NCA WIRE
ORG/ WIRE
PANORAMA SUNROOF
PASSENGER DOOR LAMP
PNK WIRE
POWER CONNECTOR ROOM LP FUSE
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RIGHT HEAD- LAMP
RIGHT REAR COMBINATION LAMP (IN)
RIGHT REAR COMBINATION LAMP (OUT)
ROOM LAMP RELAY
SUNROOF FUSE
T/SIG SOUND RELAY
T/SIG SOUND RLY CTRL
T/TURN DOOR UNLOCK RELAY
TIRE PRESSURE MONITORING MODULE
TO ROOM LP FUSE (DIAGRAM 3 OF 6)
TRUNK ROOM LAMP
W/O FRONT FRONT MONITOR MONITOR
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, hybrid (3 of 6) -> AUTO LIGHT, PHOTO SENSOR FRONT CLOCK RF MONITOR RECEIVER
