Hyundai Sonata VI (2009-2014) 18 33 53 rly ctrl hi rly ctrl lo ecu Wiring diagrams
This page contains all the electrical diagrams for the component. 18 33 53 rly ctrl hi rly ctrl lo ecu, in which he is found in the car Hyundai Sonata VI (2009-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 18 33 53 rly ctrl hi rly ctrl lo ecu (1 of 2)
18 33 53 RLY CTRL HI RLY CTRL LO ECU
BLK WIRE
BLU WIRE
BLU/ORG WIRE
C/FAN FUSE
C/FAN HI FUSE
C/FAN RELAY
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR (BEHIND RADIATOR)
E/R FUSE, RELAY BOX
E/R-A
E/R-B
ECT GND CHTG-AG
ECT SIG
ECU 1 FUSE
ECU RELAY
EMS BOX
ENGINE COOLANT TEMPERATURE SENSOR (REAR OF CYLINDER HEAD)
HOT AT ALL TIMES
MULTI FUSE
NCA WIRE
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
RED WIRE
RLY CTRL 77 60 CHTG-BG C-CAN HI C-CAN LO
SENSOR 1 FUSE
WHT WIRE
YEL WIRE
Go to component -> 2.0l, cooling fan circuit -> 18 33 53 RLY CTRL HI RLY CTRL LO ECU
Wiring diagram 18 33 53 rly ctrl hi rly ctrl lo ecu (2 of 2)
18 33 53 RLY CTRL HI RLY CTRL LO ECU
BLK WIRE
BLU WIRE
BLU/ORG WIRE
C/FAN FUSE
C/FAN RELAY
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR (BEHIND RADIATOR)
E/R FUSE, RELAY BOX
E/R-A
E/R-B
ECT GND CHG-AG
ECT SIG
ECU 1 FUSE
ECU RELAY
EMS BOX
ENGINE COOLANT TEMPERATURE SENSOR, SENDER (REAR OF CYLINDER HEAD)
HOT AT ALL TIMES
NCA WIRE
ORG/ WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
RED WIRE
RLY CTRL 77 60 CHG-BG C-CAN HI C-CAN LO
SENSOR 1 FUSE
WHT WIRE
YEL WIRE
Go to component -> 2.4l, cooling fan circuit -> 18 33 53 RLY CTRL HI RLY CTRL LO ECU
