Radio circuit, with jbl for Hyundai Sonata V facelift (2007-2010)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 SAT LCH (+) SAT RCH (+) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 XM SDARS L (+) XM SDARS L (-) 1 2 3 4 5 6 7 8 9 10 11 12 13 MEMORY POWER ACC/ON IN ILL (+) ILL (-) REMOTE 14 15 16 17 18 19 20 21 22 23 24 CAN-H CAN-L ACC/ON IN SAT LCH (-) SAT RCH (-) GROUND AUDIO AUDIO POWER BLK WIRE BLOCK (BEHIND LEFT SIDE OF DASH) BLU WIRE BLU/ORG WIRE BRN WIRE CAN-L CAN-H CIRCUIT CLOCK- SPRING D/CLOCK FUSE DOWN F/CABLE FEEDER CABLE FL (+) RL (+) RR (+) FR (+) FR (-) GROUND FL (-) RL (-) RR (-) ANTENNA PNK WIRE GLASS ANTENNA MODULE (IN RIGHT "C" PILLAR) GRN WIRE GRN/BLK WIRE GROUND GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON I/P-D I/P-E ILLUM LEFT AUDIO REMOCON SWITCH MODE MULTI- FUNCTION SWITCH MUTE NCA WIRE ORG/ WIRE ORG/BLK WIRE P/AMP FUSE PASSENGER COMPARTMENT JUNCTION PNK WIRE PNK/BLK WIRE POWER CONNECTOR AUDIO FUSE RED WIRE RED/ORG WIRE REMOCON SIGNAL REMOCON GROUND SET TOP BOX STEERING WHEEL) VOL (-) VOL UP W/ AUDIO REMOCON WHT WIRE WHT/BLK WIRE XM SDARS R (+) XM SDARS R (-) YEL WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 GROUND RR (+) RL (+) BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE FL (+) MEMORY POWER FR HI (-) FL HI (-) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRY/BLK WIRE JBL AMPLIFIER (RIGHT SIDE OF LUGGAGE COMPT) LEFT FRONT DOOR SPEAKER LEFT FRONT TWEETER SPEAKER LEFT REAR DOOR SPEAKER NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK RL (-) FR (-) FL (-) WIRE PNK WIRE PNK/BLK WIRE RED WIRE RED/ORG WIRE RIGHT FRONT DOOR SPEAKER RIGHT FRONT TWEETER SPEAKER RIGHT REAR DOOR SPEAKER WHT WIRE WHT/BLK WIRE WHT/ORG WIRE WOOFER SPEAKER YEL WIRE YEL/ORG WIRE
