Hyundai Sonata V facelift (2007-2010) dcc sol val ctrl vfs sol val ctrl ground Wiring diagram

BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE DCC SOL VAL CTRL VFS SOL VAL CTRL GROUND DOWN SHIFT SWITCH ENGINE COMPARTMENT JUNCTION BLOCK (AT LEFT FRONT CORNER OF ENGINE COMPARTMENT) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/WHT WIRE GROUND GROUND ATM CTRL RELAY GRY WIRE GRY/BLK WIRE LR SOL VAL CTRL MANUAL NORMAL OD SOL VAL CTRL OIL TMP SENSOR SENSOR GROUND PULSE GENTR B ORG/ WIRE P INPUT R INPUT N INPUT D INPUT SEL SW UP SHIFT DOWN SHIFT PNK UD SOL VAL CTRL BATT VOL BATT VOL PWM INPUT WIRE PNK WIRE PULSE GENTR A RED WIRE SELECT SWITCH SHIFT INTERLOCK SYSTEM SPORT MODE SWITCH STARTING/ CHARGING SYSTEM STOP LP SW TCM (LEFT REAR OF ENGINE COMPARTMENT) TRANSAXLE RANGE SWITCH (TOP OF TRANSAXLE) UP SHIFT SWITCH WHT WIRE YEL WIRE
