Hyundai Sonata V facelift (2007-2010) coil ground control Wiring diagram
This page shows the only wiring diagram for the component.coil ground control, which is found in the car Hyundai Sonata V facelift (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram coil ground control (1 of 1)
BCM (UNDER FRONT OF CENTER CONSOLE)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
COIL GROUND CONTROL
FLASHER UNIT (BEHIND LEFT SIDE OF DASH)
GRN WIRE
GRY WIRE
HAZARD FUSE
HAZARD RELAY (W/ B/ ALARM)
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
I/P-A
I/P-B
I/P-D
I/P-D PNK WIRE
I/P-K
I/P-L
ILLUMINATION
LEFT HEAD- LAMP
LEFT RIGHT
LEFT SIDE MARKER LAMP TURN
LEFT TURN INDICATOR
MULTI- FUNCTION SWITCH
NCA WIRE
OFF ON
ORG/ WIRE
PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
PASSENGER COMPARTMENT RELAY BOX (BEHIND LEFT SIDE OF DASH)
POWER
RED WIRE
RELAY CTRL
RIGHT HEAD- LAMP
RIGHT SIDE MARKER LAMP
RIGHT TURN INDICATOR
T/SIG FUSE
TURN
TURN SIGNAL SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> COIL GROUND CONTROL
