Car Wiring Diagrams for Immobilizer circuit for Hyundai Sonata V (2004-2007)

2.4L A/T ANTENNA BLK WIRE BLK/ORG WIRE BLU WIRE BRN/WHT WIRE CODE DATA LINK CONNECTOR (UNDER DASH LEFT OF STEERING COLUMN) DIAGNOSIS ECM (BEHIND LOWER CENTER OF DASH) ETACM (IN PASSENGER COMPARTMENT JUNCTION BLOCK) FUSE 18 (BEHIND LEFT SIDE OF DASH) FUSE 24 GRN WIRE GROUND HOT AT ALL TIMES HOT IN ON OR START I/P-G IMMO IND IMMOBILIZER CONTROL MODULE (CENTER OF DASH) IMMOBILIZER INDICATOR INSTRUMENT CLUSTER JOINT JOINT CONNECTOR K LINE M/T MEMORY MULTIPURPOSE CHECK CONNECTOR (UNDER DASH, TO LEFT OF STEERING COLUMN) NCA WIRE ORG/ WIRE ORG/BLK WIRE PASSENGER COMPARTMENT JUNCTION BLOCK PCM (BEHIND LOWER CENTER OF DASH) PNK INPUT WIRE PNK WIRE PPL PPL SIGNAL WHT WIRE WHT/BLK WIRE YEL WIRE
