Hyundai Sonata V (2004-2007) nca Wiring diagrams

This page contains all the electrical diagrams for the component. nca, in which he is found in the car Hyundai Sonata V (2004-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram nca (41 of 55)

Wiring diagram nca for Hyundai Sonata V (2004-2007) (41 of 55)
Get lifetime access to Hyundai Sonata V (2004-2007)

A/T PNK FR WIRE BATTERY BATTERY GROUND BLK WIRE BLU WIRE CHARGE INDICATOR ECM (BEHIND LOWER CENTER OF DASH) ECM FUSE ETACM FUSE 18 FUSIBLE LINK GENERATOR FR GRY WIRE HEADLIGHTS SYSTEM (DRL CONTROL MODULE) (IF EQUIPPED) HOT IN ON OR START I/P-G I/P-M INSTRUMENT CLUSTER JOINT CONNECTOR M/T PNK FR WIRE NCA WIRE ORG/ WIRE PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) PCM (BEHIND LOWER CENTER OF DASH) PNK WIRE PRE- EXCITATION RESISTOR WHT WIRE

Go to component -> 2.4l, charging circuit -> NCA WIRE

Wiring diagram nca (42 of 55)

Wiring diagram nca for Hyundai Sonata V (2004-2007) (42 of 55)
Get lifetime access to Hyundai Sonata V (2004-2007)

A/T BLK WIRE BRN WIRE ELECTRONIC CHROME MIRROR ENGINE COMPARTMENT JUNCTION BLOCK (AT LEFT FRONT CORNER OF ENGINE COMPARTMENT) FUSE 17 FUSE 5 GROUND HOT IN ON HOT IN ON OR START I/P-B PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) I/P-E PNK WIRE I/P-J I/P-J I/P-D LT GRN WIRE NCA WIRE ON INPUT PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) PNK M/T WIRE PNK WIRE TRANSAXLE RANGE SW ``R" POSITION TRANSMISSIONS SYSTEM

Go to component -> Electrochromic mirror circuit, without home link -> NCA WIRE

Wiring diagram nca (43 of 55)

Wiring diagram nca for Hyundai Sonata V (2004-2007) (43 of 55)
Get lifetime access to Hyundai Sonata V (2004-2007)

BLK WIRE BRN WIRE BRN/WHT WIRE FUSE 15 GRY WIRE HOT IN ON I/P-G ILLUM IND LEFT FRONT SEAT WARMER LEFT FRONT SEAT WARMER SWITCH NCA WIRE PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) PNK WIRE PNK/BLK WIRE RIGHT FRONT SEAT WARMER RIGHT FRONT SEAT WARMER SWITCH SEAT WARMER THERMOSTAT

Go to component -> Heated seats circuit -> NCA WIRE

Wiring diagram nca (44 of 55)

Wiring diagram nca for Hyundai Sonata V (2004-2007) (44 of 55)
Get lifetime access to Hyundai Sonata V (2004-2007)

BLK WIRE DEFOGGER SYSTEM DOWN DOWN/ LEFT FUSE 30 HOT IN ACC OR ON I/P-G LEFT LEFT DOOR MIRROR MOTOR, DEFOGGER LEFT/ RIGHT SWITCH RIGHT LEFT/RIGHT LT BLU WIRE LT GRN WIRE NCA WIRE PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) POWER DOOR MIRROR SWITCH PPL RED WIRE RIGHT DOOR MIRROR MOTOR, DEFOGGER SELECTOR SWITCH RIGHT UP/ DOWN SWITCH UP/ RIGHT UP/DOWN UP/DOWN LEFT/RIGHT WHT WIRE YEL WIRE

Go to component -> Power mirrors circuit -> NCA WIRE

Wiring diagram nca (45 of 55)

Wiring diagram nca for Hyundai Sonata V (2004-2007) (45 of 55)
Get lifetime access to Hyundai Sonata V (2004-2007)

BACK BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/YEL WIRE DOWN FORWARD/ FRONT HEIGHT FRONT HEIGHT ADJUSTER FUSE 7 GRN/RED WIRE HOT AT ALL TIMES I/P-C LT GRN/BLK WIRE LT GRN/WHT WIRE NCA WIRE ORG/ WIRE PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) POWER SEAT ADJUSTER SWITCH REAR HEIGHT REAR HEIGHT ADJUSTER RECLINING RECLINING ADJUSTER RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SLIDE SLIDE ADJUSTER SLIDE ADJUSTER LIMIT SWITCH WHT/BLK WIRE YEL/RED WIRE YEL/WHT WIRE

Go to component -> Power seat circuit -> NCA WIRE

Wiring diagram nca (46 of 55)

Wiring diagram nca for Hyundai Sonata V (2004-2007) (46 of 55)
Get lifetime access to Hyundai Sonata V (2004-2007)

BLK WIRE BLU WIRE BRN WIRE CLOSE OPEN CLOSE/ TILT UP COMPUTER DATA LINES SYSTEM ENGINE COMPARTMENT JUNCTION BLOCK (AT LEFT FRONT CORNER OF ENGINE COMPT) FUSE 5 GRN WIRE HOT AT ALL TIMES HOT IN ON I/P-D I/P-G I/P-J LIMIT SWITCH LIMIT SWITCH TILT UP NCA WIRE OPEN/TILT DOWN ORG/ WIRE OVERHEAD CONSOLE ASSEMBLY SUN ROOF SWITCH PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) RED WIRE ROOF CLOSED ROOF OPEN SUN ROOF MOTOR (AT FRONT OF SUN ROOF OPENING) SUN ROOF RELAY (AT FRONT OF SUN ROOF OPENING) SUNROOF FUSE TILT DOWN TILT UP WHT WIRE YEL WIRE

Go to component -> Power top/sunroof circuit -> NCA WIRE

Wiring diagram nca (47 of 55)

Wiring diagram nca for Hyundai Sonata V (2004-2007) (47 of 55)
Get lifetime access to Hyundai Sonata V (2004-2007)

AUTO DOWN/UP CONTROL UNIT BLK WIRE BLU WIRE BRN WIRE DOOR LOCKS SYSTEM DOOR UNLOCK SWITCH ELECTRONIC TIME, ALARM CONTROL MODULE (ETACM) ENGINE COMPARTMENT JUNCTION BLOCK (AT LEFT FRONT CORNER OF ENGINE COMPT) EXPRESS DOWN GRN WIRE HOT AT ALL TIMES I/P-B ILLUM LEFT FRONT POWER WINDOW MOTOR LEFT FRONT WINDOW SWITCH LEFT REAR POWER WINDOW MOTOR LEFT REAR POWER WINDOW SWITCH LEFT REAR WINDOW SWITCH LT BLU WIRE LT GRN WIRE NCA WIRE OFF DOWN OFF DOWN ILLUM UP OFF DOWN UP OFF OFF DOWN UP DOWN UP OFF OFF DOWN UP ILLUM DOWN UP OFF UP DOWN OFF UP ILLUM DOWN PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) POWER WINDOW FUSIBLE LINK POWER WINDOW MAIN SWITCH POWER WINDOW RELAY PPL RED WIRE RIGHT FRONT POWER WINDOW MOTOR RIGHT FRONT POWER WINDOW SWITCH RIGHT FRONT WINDOW SWITCH RIGHT REAR POWER WINDOW MOTOR RIGHT REAR POWER WINDOW SWITCH RIGHT REAR WINDOW SWITCH TAN WIRE UN- LOCK LOCK UNLOCK LOCK WHT WIRE WINDOW LOCK SWITCH

Go to component -> Power windows circuit -> NCA WIRE

Wiring diagram nca (48 of 55)

Wiring diagram nca for Hyundai Sonata V (2004-2007) (48 of 55)
Get lifetime access to Hyundai Sonata V (2004-2007)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 LF SPEAKER AMP 1 AMP 2 AUDIO AUDIO CABLE BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE BRN/WHT WIRE ENGINE COMPARTMENT JUNCTION BLOCK (AT LEFT FRONT CORNER OF ENGINE COMPARTMENT) FUSE 24 FUSE 26 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON I/P-E I/P-F I/P-G JOINT CONNECTOR LEFT FRONT SPEAKER LEFT REAR SPEAKER LEFT TWEETER SPEAKER LR SPEAKER GROUND GROUND MEM POWER RR SPEAKER LR SPEAKER MEM POWER RR SPEAKER LT GRN WIRE NCA WIRE ORG/ WIRE PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) POWER AMP FUSE POWER ANTENNA SYSTEM RED WIRE REMOTE CTRL AMP CTRL AMP CTRL ILL (+) MEM POWER RF SPEAKER (+) RF SPEAKER LF SPEAKER RIGHT FRONT SPEAKER RIGHT REAR SPEAKER RIGHT TWEETER SPEAKER TAN WIRE WHT WIRE YEL WIRE

Go to component -> Radio circuit, with amplifier -> NCA WIRE

Wiring diagram nca (49 of 55)

Wiring diagram nca for Hyundai Sonata V (2004-2007) (49 of 55)
Get lifetime access to Hyundai Sonata V (2004-2007)

16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 MEM PWR ILL (+) RR SPEAKER RF SPEAKER AUDIO BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE BRN/WHT WIRE FUSE 24 FUSE 26 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR ACC I/P-G JOINT CONNECTOR LEFT FRONT SPEAKER LEFT REAR SPEAKER LEFT TWEETER SPEAKER LT GRN WIRE NCA WIRE ORG/ WIRE PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) POWER ANTENNA SYSTEM RED WIRE RIGHT FRONT SPEAKER RIGHT REAR SPEAKER RIGHT TWEETER SPEAKER TAN WIRE WHT WIRE YEL WIRE

Go to component -> Radio circuit, without amplifier -> NCA WIRE

Wiring diagram nca (50 of 55)

Wiring diagram nca for Hyundai Sonata V (2004-2007) (50 of 55)
Get lifetime access to Hyundai Sonata V (2004-2007)

2.4L BATTERY BATTERY GROUND BLK WIRE BURGLAR ALARM RELAY BURGLAR ALARM RELAY CONTROL ECM (BEHIND LOWER CENTER OF DASH) ENGINE COMPARTMENT JUNCTION BLOCK (AT LEFT FRONT CORNER OF ENGINE COMPARTMENT) ETACM (IN PASSENGER COMPARTMENT JUNCTION BLOCK) FUSE 18 FUSE 19 GRN WIRE I/P-A I/P-D I/P-G IGNITION LOCK SWITCH IGNITION SWITCH IGNITION SWITCH FUSIBLE LINK 1 IGNITION SWITCH FUSIBLE LINK 2 MOTOR NCA WIRE PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) PASSENGER COMPARTMENT RELAY BOX (BEHIND LEFT SIDE OF DASH) PNK WIRE PPL PPL (OR RED WIRE SIGNAL SOLENOID START RELAY W/ BURGLAR ALARM W/ IGNITION LOCK W/O BURGLAR ALARM W/O IGNITION LOCK YEL (OR GRN) WIRE YEL WIRE

Go to component -> Starting circuit, m/t -> NCA WIRE
