Hyundai Sonata V (2004-2007) door lock/unlock rly ctrl Wiring diagram
This page shows the only wiring diagram for the component.door lock/unlock rly ctrl, which is found in the car Hyundai Sonata V (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door lock/unlock rly ctrl (1 of 1)
BLK WIRE
BLU/ORG WIRE
COMPUTER DATA LINES SYSTEM SPEEDOMETER
DEFOGGER SWITCH INPUT
DEFOGGER SYSTEM
DEFOGGER SYSTEM DEFOGGER RELAY CONTROL
DOOR KEY HOLE ILLUMINATION
DOOR LOCK/UNLOCK RLY CTRL
DOOR LOCK/UNLOCK RLY CTRL DOOR LOCKS SYSTEM
DOOR LOCKS SYSTEM
DOOR SWITCH
DOOR SWITCH INTERIOR LIGHTS SYSTEM
ENGINE RUNNING INPUT
ETACM
EXTERIOR LIGHTS SYSTEM TAIL LMP RELAY AUTO CUT CTRL IN
FUSE 18
FUSE 24
FUSE 5
GRN WIRE
GROUND
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
I/P-D
I/P-F
I/P-J
I/P-L
ILLUM
JOINT
JUNCTION BLOCK GROUND
LT BLU WIRE
LT GRN/BLK WIRE
MEMORY POWER
NCA WIRE
ON INPUT
ON/START INPUT
ORG/ WIRE
PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
PNK WIRE
PNK/BLK WIRE
POWER WINDOWS SYSTEM POWER WINDOW RELAY CTRL
PPL PPL
PRE- EXCITATION RESISTOR
REAR DOOR LOCK/UNLOCK IN
ROOM LAMP CONTROL
STARTING/ CHARGING SYSTEM
Go to component -> Body control modules circuit (2 of 2) -> DOOR LOCK/UNLOCK RLY CTRL
