Car Wiring Diagrams for Automatic a/c circuit for Hyundai Sonata IV facelift (2001-2012)

A/C CONTROL MODULE (LOWER CENTER OF DASH) A/CON FUSE AMBIENT SENS (+) AMBIENT SENSOR (LOWER CENTER FRONT OF RADIATOR) BLK WIRE BLK/WHT WIRE BLOWER MOTOR (BEHIND RIGHT SIDE OF DASH) BLOWER RELAY BLU WIRE BLU/ORG WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM PNK WIRE DRIVER TEMPERATURE SENSOR DRV TEMP ACTR F/B EPS FUSE FIELD EFFECT TRANSISTOR (BEHIND RIGHT SIDE OF DASH) GRN WIRE GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON I/P-A I/P-B I/P-C I/P-K INTAKE ACTUATOR (UNDER RIGHT SIDE OF DASH) K LINE MEMORY FUSE MODE ACTUATOR (UNDER LEFT SIDE OF DASH) ORG/ WIRE PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) PNK WIRE POWER CONNECTOR RED/BLK WIRE TEMPERATURE ACTUATOR (RIGHT FRONT CENTER CONSOLE) WATER TEMPERATURE SENSOR WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE

18 26 A/C REQUEST SW A/C COMP SWITCH 2.4L 3.3L 33 7 GND SIGNAL 66 43 64 COOLING FAN CTRL ENG CTRL RLY CTRL A/C RLY CTRL A/C COMPRESSOR (3.3L: TOP FRONT OF ENGINE) (2.4L: TOP RIGHT FRONT OF ENGINE) A/C RELAY A/CON FUSE BLK WIRE BLK/WHT WIRE BLOWER FUSIBLE LINK BLU WIRE BRN WIRE COOLING FAN CONTROLLER (LEFT FRONT OF ENGINE COMPT) COOLING FAN FUSIBLE LINK COOLING FAN MOTOR COOLING FAN RELAY (UNDER BATTERY) COOLING FUSIBLE LINK BOX (2.4L) FRONT FUSIBLE LINK BOX (3.3L) ECU RLY FUSIBLE LINK ENGINE CONTROL RELAY ENGINE COOLANT GRN WIRE GRN/BLK WIRE HOT AT ALL TIMES MICOM NCA WIRE ORG/ WIRE PCM (LEFT REAR OF ENGINE COMPT) PHOTO SENSOR PNK 65 64 87 WIRE PNK WIRE POWER CONDITIONING SECURITY INDICATOR, AUTO LIGHT, PHOTO SENSOR (TOP LEFT SIDE OF DASH) SNSR 3 FUSE WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL WIRE
