Hyundai Sonata IV facelift (2001-2012) seats, shift interlock systems Wiring diagrams

A/C CONTROL MODULE AUTOMATIC A/C ABS CONTROL MODULE (LEFT REAR OF ENGINE COMPT) ACCEL POSITION SENSOR (AT TOP OF ACCELERATOR PEDAL ASSEMBLY) ATM KEY LOCK CONTROL MODULE (BEHIND LOWER AUDIO B/UP FUSE BCM (BODY CONTROL MODULE) BLK WIRE BLK/ORG WIRE BLU WIRE BLU/RED WIRE DATA LINK CONNECTOR (UNDER DASH LEFT OF STEERING COLUMN) ENGINE COMPARTMENT JUNCTION BLOCK (AT LEFT FRONT CORNER OF ENGINE COMPT) ETC MOTOR, THROTTLE POSITION SENSOR (LEFT REAR OF ENGINE) GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START M/T MODULE (UNDER FRONT OF CENTER CONSOLE) MOTOR ORG/ WIRE PNK WIRE PNK/BLK WIRE RED WIRE SEATS, SHIFT INTERLOCK SYSTEMS STOP FUSE STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET) THROTTLE POSITION SENSOR TIRE PRESSURE MONITORING VEHICLE SPEED SENSOR (M/T) (ON TOP OF TRANSAXLE) W/ ESC W/O ESC WHT WIRE WHT/BLK WIRE YEL WIRE YEL/ORG WIRE

18 19 PNK WIRE A/C CONTROL MODULE AUTOMATIC A/C A/T M/T ABS CONTROL MODULE (LEFT REAR OF ENGINE COMPT) ACCEL POSITION SENSOR (AT TOP OF ACCELERATOR PEDAL ASSEMBLY) ATM KEY LOCK CONTROL MODULE (BEHIND LOWER AUDIO B/UP FUSE BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE DATA LINK CONNECTOR (UNDER DASH LEFT OF STEERING COLUMN) ENGINE COMPARTMENT JUNCTION BLOCK (AT LEFT FRONT CORNER OF ENGINE COMPT) ETC MOTOR, THROTTLE POSITION SENSOR GRN WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START MODULE (UNDER FRONT OF CENTER CONSOLE) ORG/ WIRE PNK WIRE RED WIRE SEATS, SHIFT INTERLOCK SYSTEMS SPORT MODE SWITCH STOP FUSE STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET) TIRE PRESSURE MONITORING W/ ESC W/O ESC WHT WIRE WHT/BLK WIRE YEL WIRE
