Hyundai Sonata IV facelift (2001-2012) key ill control Wiring diagram
This page shows the only wiring diagram for the component.key ill control, which is found in the car Hyundai Sonata IV facelift (2001-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram key ill control (1 of 1)
BLK WIRE
BLK/ORG WIRE
BODY CONTROL MODULE (BCM) (UNDER FRONT OF CENTER CONSOLE)
BRN/ORG WIRE
CLUSTER FUSE
DIGITAL CLOCK
DOOR AJAR IND
DOOR WARNING SW
DRIVER DOOR KEY UNLOCK SIG
DRIVER DOOR LOCK ACTUATOR (REAR OF LEFT FRONT DOOR)
DRIVER SEAT BELT IND
DRIVER SEAT BUCKLE SWITCH
DRIVER SEAT BUCKLE SWITCH (UNDER DRIVER FRONT SEAT)
DRIVER/PASSENGER DOOR KEY LOCK SIG
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HEAD
HOT AT ALL TIMES
HOT IN ON OR START
I/P-A
I/P-B
I/P-D
I/P-L
INSTRUMENT CLUSTER
JOINT
JOINT CONNECTOR
KEY ILL CONTROL
KEY LOCK KEY UNLOCK
LIGHT SWITCH
MEMORY FUSE
MULTI- FUNCTION SWITCH
NCA WIRE
ON/START
ORG/ WIRE
ORG/BLK WIRE
PARK OFF
PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
PNK DOOR SWITCH WIRE
PNK TAIL LAMP RLY AUTO CUT CTRL OUTPUT WIRE
PNK WIRE
POWER CONNECTOR
RED WIRE
SEAT BELT IND
SEAT BELT REMINDER IND
SEAT BELT REMINDER INDICATOR
SEAT BELT/ KEY OPERATING WARNING CHIME BUZZER
WHT WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Chime circuit -> KEY ILL CONTROL
