Hyundai Sonata IV facelift (2001-2012) atm key lock control module Wiring diagram
This page shows the only wiring diagram for the component.atm key lock control module, which is found in the car Hyundai Sonata IV facelift (2001-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram atm key lock control module (1 of 1)
ADJUSTABLE PEDAL SWITCH
ATM KEY LOCK CONTROL MODULE
AUTOMATIC A/C
BCM
BLK WIRE
BLOWER RELAY
COOLING FAN CONTROLLER
DATA LINK CONNECTOR
DIGITAL CLOCK
DOOR LOCK RELAY
DRIVER SEAT BUCKLE SWITCH
DRIVER SEAT WARMER SWITCH
DRL CONTROL MODULE
FLASHER UNIT
GLOVE BOX LAMP/ SWITCH
I/P-B
I/P-D
I/P-E
INSTRUMENT CLUSTER
JOINT CONNECTOR
LEFT FRONT FOG LAMP
LEFT HEADLAMP
MANUAL A/C
MULTI- FUNCTION SWITCH
MULTIPURPOSE CHECK CONNECTOR
NCA WIRE
PASSENGER COMPARTMENT RELAY BOX (BEHIND LEFT SIDE OF DASH)
PASSENGER SEAT WARMER SWITCH
RED WIRE
RHEOSTAT
RIGHT FRONT HOOD FOG SWITCH LAMP
RIGHT HEADLAMP
STEERING ANGLE SENSOR
T/TURN UNLOCK RELAY
TIRE PRESSURE MONITORING SMATRA MODULE (IMMOBILIZER)
TRIP MODE RESET
WASHER LEVEL SENSOR
WASHER MOTOR
WHT WIRE
Go to component -> Ground distribution circuit (2 of 4) -> ATM KEY LOCK CONTROL MODULE
