Hyundai Sonata IV (1998-2001) pnk pnk engine controls system Wiring diagram
This page shows the only wiring diagram for the component.pnk pnk engine controls system, which is found in the car Hyundai Sonata IV (1998-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk pnk engine controls system (1 of 1)
A/C SIG INPUT
AIR CONDITIONING SYSTEM
B+ H- H+ L-
BLK WIRE
BLU WIRE
CONDENSER FAN MOTOR
CONDENSER FAN RELAY (HIGH 1)
CONDENSER FAN RELAY (HIGH 2)
CONDENSER FAN RELAY (LOW)
CONDENSER FUSIBLE LINK
ECM CONTROL RELAY (BEHIND DASH, ON RIGHT SIDE OF CENTER SUPPORT BRACKET)
ECM RLY CTRL
ENGINE COMPARTMENT JUNCTION BLOCK
ENGINE CONTROL MODULE (ECM) (BEHIND LOWER CENTER OF DASH) FAN RLY (LOW) CTRL
FAN RLY (HI) CTRL
FROM RADIATOR/ CONDENSER FAN RELAYS
GRN WIRE
GRY WIRE
H+ L- B+ H-
HOT AT ALL TIMES
LT BLU WIRE
MAIN FUSE
NCA WIRE
ORG/ WIRE
PNK PNK ENGINE CONTROLS SYSTEM WIRE
PNK WIRE
RADIATOR FAN MOTOR
RADIATOR FAN RELAY (HIGH 1)
RADIATOR FAN RELAY (HIGH 2)
RADIATOR FAN RELAY (LOW)
RADIATOR FUSIBLE LINK
RED WIRE
TO ENGINE CONTROL MODULE (ECM)
TRIPLE SWITCH (TOP OF RECEIVER- DRIER ASSEMBLY)
WHT WIRE
YEL WIRE
Go to component -> 2.5l, cooling fan circuit -> PNK PNK ENGINE CONTROLS SYSTEM WIRE
