Hyundai Sonata IV (1998-2001) ecm rly ctrl Wiring diagrams
This page contains all the electrical diagrams for the component. ecm rly ctrl, in which he is found in the car Hyundai Sonata IV (1998-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ecm rly ctrl (1 of 2)
A/C SIG INPUT
AIR CONDITIONING SYSTEM
B+ H- H+ L-
BLK WIRE
BLU WIRE
CONDENSER FAN MOTOR
CONDENSER FAN RELAY (HIGH 1)
CONDENSER FAN RELAY (HIGH 2)
CONDENSER FAN RELAY (LOW)
CONDENSER FUSIBLE LINK
ECM CONTROL RELAY (BEHIND DASH, ON RIGHT SIDE OF CENTER SUPPORT BRACKET)
ECM RLY CTRL
ENGINE COMPARTMENT JUNCTION BLOCK
ENGINE CONTROL MODULE (ECM) (BEHIND LOWER CENTER OF DASH) FAN RLY (LOW) CTRL
FAN RLY (HI) CTRL
FROM RADIATOR/ CONDENSER FAN RELAYS
GRN WIRE
GRY WIRE
H+ L- B+ H-
HOT AT ALL TIMES
LT BLU WIRE
MAIN FUSE
NCA WIRE
ORG/ WIRE
PNK PNK ENGINE CONTROLS SYSTEM WIRE
PNK WIRE
RADIATOR FAN MOTOR
RADIATOR FAN RELAY (HIGH 1)
RADIATOR FAN RELAY (HIGH 2)
RADIATOR FAN RELAY (LOW)
RADIATOR FUSIBLE LINK
RED WIRE
TO ENGINE CONTROL MODULE (ECM)
TRIPLE SWITCH (TOP OF RECEIVER- DRIER ASSEMBLY)
WHT WIRE
YEL WIRE
Go to component -> 2.5l, cooling fan circuit -> ECM RLY CTRL
Wiring diagram ecm rly ctrl (2 of 2)
1 2 3 4 5 6 7 GROUND ON INPUT DEFROST MIX FLOOR B/L VENT
8 9 PNK PNK BATTERY VOLTAGE BATTERY VOLTAGE WIRE
A/C SWITCH
BLEND DOOR ACTUATOR (BEHIND CENTER OF DASH, ON LEFT END OF HVAC HOUSING)
BLK WIRE
BLOWER FUSE
BLOWER RELAY (BEHIND RIGHT KICK PANEL)
BLOWER RESISTOR (BEHIND RIGHT SIDE OF DASH, ON HVAC HOUSING)
BLOWER SWITCH
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CRUISE CONTROL SWITCH
DEFOGGER SYSTEM
DEFOGGER SYSTEM INTERIOR LIGHTS SYSTEM
ECM RLY CTRL
ENGINE COMPARTMENT JUNCTION BLOCK (AT LEFT FRONT CORNER OF ENGINE COMPARTMENT)
ENGINE CONTROL MODULE (ECM) (BEHIND LOWER CENTER OF DASH)
FUSE 2
FUSE 22
FUSE 8
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ON
INTAKE ACTUATOR (BEHIND RIGHT SIDE OF DASH, ON RIGHT END OF HVAC HOUSING)
J/C (BEHIND LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MID
NCA WIRE
OFF 4 5 3 6 (I) L (II) ML (III) MH PPL (IIII) HI OFF (I) L (II) ML
PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
PNK PNK 1 2 3 4 5 6 7 WIRE
PNK PPL WIRE
PNK/WHT WIRE
PPL
PPL BLOWER MOTOR (BEHIND RIGHT SIDE OF DASH, ON BOTTOM OF HVAC HOUSING)
PPL PNK WIRE
RED WIRE
TAN WIRE
THERMOSTATIC SWITCH (BEHIND RIGHT SIDE OF DASH, ON EVAPORATOR UNIT)
WHT WIRE
YEL WIRE
Go to component -> 2.5l, manual a/c circuit (1 of 2) -> ECM RLY CTRL
