Car Wiring Diagrams for Starting circuit for Hyundai Sonata III facelift (1996-1998)

5 11 (3.0L) (2.0L) A/T BATTERY BATTERY GROUND BLK WIRE BLK/WHT WIRE BLU/RED (OR BLK) WIRE BLU/RED WIRE CHARGING SYSTEM (GENERATOR 3.0L ONLY) CRUISE CONTROL MODULE DK BLU WIRE ENGINE COMPARTMENT FUSE/RELAY BOX ENGINE COMPARTMENT FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT) ENGINE CONTROL MODULE ENGINE CONTROL SYSTEM FUSIBLE LINK B FUSIBLE LINK C HOLD- IN COIL IGNITION SWITCH LOCK ON M/T M/T A/T MOTOR NCA WIRE PNK WIRE PULL- IN COIL RED WIRE RED/BLU WIRE RELAY SOLENOID STARTER CLUTCH PEDAL POSITION SWITCH TRANSMISSION RANGE SWITCH (LOWER RIGHT SIDE OF ENGINE, ON TOP OF TRANSMISSION) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLU OR YEL WIRE YEL/RED (OR BLK/YEL) WIRE YEL/WHT WIRE
