Hyundai Sonata III facelift (1996-1998) rear window defogger relay rear window defogger timer module Wiring diagram
This page shows the only wiring diagram for the component.rear window defogger relay rear window defogger timer module, which is found in the car Hyundai Sonata III facelift (1996-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear window defogger relay rear window defogger timer module (1 of 1)
2.0L
3.0L
A/T SHIFT LEVER
BLK WIRE
BLK/BLU WIRE
BLOWER RELAY
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CONDENSER FAN RELAY (HIGH)
CONDENSER FAN RELAY (LOW)
DASH FUSE BOX
DATA LINK CONNECTOR
DAYTIME RUNNING LAMP CONTROL MODULE
DAYTIME RUNNING LAMP RELAY
DIODE
DIODE W/ DRL
DOOR KEY ILLUM- INATION DOOR LOCK CONTROL RELAY (W/ ETACS)
ENGINE COMPARTMENT FUSE/RELAY BOX
ENGINE CONTROL MODULE (ECM)
ENGINE CONTROL MODULE (ECM) IGNITION POWER TRANSISTOR
FRESH/RECIRC SWITCH AND HEATER CONTROL PANEL ILLUMINATION
FROM DASH FUSE BOX (DIAGRAM 3 OF 4)
FROM FUSE 23 (DIAGRAM 1 OF 4)
FROM TAIL LAMP RELAY (DIAGRAM 2 OF 4)
FUSE 13
FUSE 14
FUSE 15
FUSE 22
GRN WIRE
GRN/RED WIRE
HEADLAMP RELAY (HIGH)
HEADLAMP RELAY (LOW)
IGNITION COIL ENGINE CONTROL RELAY
IGNITION COIL ENGINE CONTROL RELAY RADIO NOISE CONDENSER
LIGHT SWITCH
MULTIFUNCTION SWITCH
NCA WIRE
OVERDRIVE SWITCH
PASSENGER COMPARTMENT RELAY BOX
POWER SEAT ADJUSTER SWITCH
POWER WINDOW RELAY
POWER/ NORMAL SWITCH
RADIATOR FAN RELAY (HIGH)
RADIATOR FAN RELAY (LOW)
REAR WINDOW DEFOGGER RELAY REAR WINDOW DEFOGGER TIMER MODULE
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
SUNROOF CLOSE/ TILT UP RELAY
SUNROOF OPEN/TILT DOWN RELAY
TRANS- MISSION RANGE SWITCH
TRANSMISSION CONTROL MODULE (2.0L)
TRANSMISSION CONTROL MODULE (3.0L)
TRUNK LID OPENER SWITCH
W/ DRL
W/ ETACS W/O ETACS
W/O DRL
W/O ETACS
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit (4 of 4) -> REAR WINDOW DEFOGGER RELAY REAR WINDOW DEFOGGER TIMER MODULE
