Hyundai Sonata III facelift (1996-1998) on/start input wiring diagram
This page shows the only wiring diagram for the component.on/start input, which is found in the car Hyundai Sonata III facelift (1996-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
on/start input wiring diagram (1 of 1)
2.0L 3.0L
3.0L 2.0L
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
CHARGING SYSTEM
DASH FUSE BOX (LEFT SIDE OF DASH)
DEFOGGER RELAY
DEFOGGER RELAY (RIGHT SIDE OF TRUNK)
DEFOGGER SWITCH
DEFOGGER SWITCH ON INPUT
ELECTRONIC TIME, ALARM CONTROL MODULE (BEHIND CENTER OF DASH)
ENGINE CONTROLS SYSTEM
ETACS, T/S, B/UP FUSE 7
GENERATOR
GENERATOR (LOWER RIGHT FRONT CORNER OF ENGINE)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ILLUMINATION
LEFT DOOR MIRROR DEFOGGER
ON OFF
ON/START INPUT
REAR DEFOGGER INDICATOR
REAR WINDOW DEFOGGER RIGHT DOOR MIRROR DEFOGGER
RED WIRE
RR DEF FUSE 15
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Defogger circuit, with etacs-ecu -> ON/START INPUT
